Spatial power combining microwave source based on single beam klystron
-
摘要: 基于常规速调管，研制了用于开展空间功率合成实验的微波源系统。介绍了50 MW超大功率速调管发射机的系统组成、大功率速调管、相位控制及高功率测试系统等。重点阐述了超大功率速调管发射机的关键技术，并针对超大功率发射机的设计难点提出了具体的解决方案。为提高超大功率发射机的可靠性，设计了基于绝缘栅双极晶体管（IGBT）的感应叠加型全固态调制器。给出了超大功率发射机的测试结果，并探讨了超大功率速调管发射机的改进方法。最后对基于常规速调管，研制用于空间功率合成微波源系统的发展进行了展望。
-
关键词:
- 微波源 /
- 50 MW常规速调管发射机 /
- 相位控制 /
- 全固态调制器 /
- 空间功率合成
Abstract: The microwave source for spatial power combining based on single beam klystron has been developed, which will meet the requirements of modern radars and high power equipments. The system composition, high power klystron, phase control and high power test system of the 50 MW super-high power klystron transmitter developed are introduced. The paper puts emphases on the key technologies of the transmitter， and provides some concrete solutions to the design difficulties. The design of the inductive-adder high-power all-solid-state modulator based on high-power IGBT modules as switches is presented, which can improve the reliability of the transmitter. The test results of the super-high power transmitter are given, which show that the transmitter satisfies technical requirements, and improvement methods for the transmitter are discussed. The future development of the microwave source for spatial power combining based on single beam klystron is forecasted. -
