航空复合涂层材料的激光烧蚀效应

李静; 郑轶; 罗晋; 陈松林; 关振威; 梁璐

doi:10.3788/HPLPB201426.029003

留言板

尊敬的读者、作者、审稿人, 关于本刊的投稿、审稿、编辑和出版的任何问题, 您可以本页添加留言。我们将尽快给您答复。谢谢您的支持!

姓名
邮箱
手机号码
标题
留言内容
验证码

航空复合涂层材料的激光烧蚀效应

李静, 郑轶, 罗晋, 陈松林, 关振威, 梁璐

文章导航 > 强激光与粒子束 > 2014 > 26: 029003

李静, 郑轶, 罗晋, 等. 航空复合涂层材料的激光烧蚀效应[J]. 强激光与粒子束, 2014, 26: 029003. doi: 10.3788/HPLPB201426.029003

引用本文:

李静, 郑轶, 罗晋, 等. 航空复合涂层材料的激光烧蚀效应[J]. 强激光与粒子束, 2014, 26: 029003. doi: 10.3788/HPLPB201426.029003

Li Jing, Zheng Yi, Luo Jin, et al. Laser ablation effect of composite coating applied to aerospace material[J]. High Power Laser and Particle Beams, 2014, 26: 029003. doi: 10.3788/HPLPB201426.029003

Citation:

Li Jing, Zheng Yi, Luo Jin, et al. Laser ablation effect of composite coating applied to aerospace material[J]. High Power Laser and Particle Beams, 2014, 26: 029003. doi: 10.3788/HPLPB201426.029003

航空复合涂层材料的激光烧蚀效应

doi: 10.3788/HPLPB201426.029003

1.
中航工业北京航空材料研究院, 北京 1 00095;
2.
成都精密光学工程研究中心, 成都 61 0041

Laser ablation effect of composite coating applied to aerospace material

1.
AVIC Beijing Institute of Aeronautical Materials,Beijing 100095,China;
2.
Chengdu Fine Optical Engineering Research Center,Chengdu 610041,China 1.AVIC Beijing Institute of Aeronautical Materials,Beijing 100095,China;

摘要: 针对航空激光防护技术研究需求，开展了复合涂层材料的激光烧蚀效应综合研究。采用圆棒固体激光器作为测试光源，搭建了具有在线温度测量功能的烧蚀实验平台。在此基础上，对聚碳硅烷(PCS)涂层样品开展了激光烧蚀实验。通过对烧蚀区域形貌和温度数据的对比分析，证明了PCS复合材料具备显著的激光防护作用。同时，从理论方面对涂层的激光防护机理进行了研究，基于材料热传导方程，建立了激光烧蚀过程的热力学模型，对温度场变化进行了模拟。研究结果表明，在复合涂层的保护下，kW级激光仅产生百℃的金属基底升温。 (1. AVIC Beijing Institute of Aeronautical Materials, Beijing 100095, China;2. Chengdu Fine Optical Engineering Research Center, Chengdu 610041, China)
- 激光烧蚀 /
- 激光防护 /
- 复合材料 /
- 航空材料 /
- 固体激光
Abstract: This paper concentrates on the measurement and analysis of laser ablation effect of particularly prepared aerospace material, polycarbosilane (PCS). Laser ablation experiment setup is designed and built, based on a continuous-wave high-power solid-state laser (CWHPSSL). Metal-shell samples with composite PCS are prepared. Then a group of laser ablation experiments are performed on those samples. They are processed by laser beam with thousands of W/cm2. The results, including the ablation morphology and temperature data, are shown and discussed. Temperature data give a good demonstration of the protection effect of composite coating, and in the meanwhile the minor-morphologies in the ablated region hint the principle of PCS laser-proof effect. After that, a theoretical investigation is carried out. Fourier equation of heat conduction is applied to modeling the temperature field during ablation process. The simulation provides a good explanation on the principle of laser-proof effect of PCS composite coating. The results demonstrate that, with the protection of PCS composite coating, kilowatt-level laser only results in hundreds of Celcius temperature increment of steel substrate.
- laser ablation /
- laser proof /
- composite coating /
- aerospace material /
- solid-state laser
