有界波EMP模拟器脉冲高压源
-
摘要: 介绍了“春雷号”有界波 EMP模拟器脉冲高压源的工作原理和其部件的结构及主要参数，给出了测试波形和计算波形。此脉冲高压源可输出前沿约为10ns，脉宽约为300ns的双指数脉冲波。Abstract: The principle and the parameters of the high voltage pulse generator which has been used in the“Spring-thunder”bounded-wave EMP simulator are described in this paper. The measured and calculated waveform are also presented. A double-exponential waveform with about 10ns risetime, and 300ns pulsewidth can be produced by this pulse generator.
-
Key words:
- emp simulator /
- marx generator /
- peaking capacitor /
- main switch
-
