大型FFAG磁铁的2维POISSON设计
Study on two-dimensional POISSON design of large-scale FFAG magnet
-
摘要: 为减小边缘场效应,大型固定磁场交变梯度(FFAG)磁铁的磁场分布由修整线圈和磁极形状两者共同来实现。通过2维POISSON模拟计算,确定了修整线圈电流和位置的分布以及磁极形状, 得到了局域磁场梯度指数与设计值之间的最大差异只有0.5%的磁场分布。为提高POISSON模拟计算的效率,POISSON输入文件中有关线圈电流和位置、磁极形状的输入和调整由程序自动完成。
-
关键词:
- 大型FFAG磁铁 /
- 2维POISSON设计 /
- 修整线圈 /
- 磁极形状
Abstract: In order to decrease the edge effect of the field, the designed magnetic field distribution in a large-scale FFAG magnet is realized by both the trim coil and the shape of the magnet pole-face. Through two-dimensional POISSON simulations, the distribution about the current and the position of the trim coil and the shape of the magnet pole are determined. In order to facilitate the POISSON design, two codes are written to automatically adjust the current and the position of the trim coil and the shape of magnet pole-face appeared in the POISSON input file. With the two codes, the efficiency of POISSON simulations is improved and the mistakes which might occur in writing and adjusting the POISSON input file manually could be avoided.-
Key words:
- large scale ffag magnet /
- two-dimension poisson design /
- trim coil /
- shape of pole-face
