Design of high power self-rotating beam scanning antenna with no phase shifter
-
摘要: 设计了一种无移相器结构的平板高功率天线，通过辐射层自旋转方式改变口径场相位分布，从而实现空间波束扫描，满足轻质、低剖面集成要求，辐射增益36 dB，波束扫描范围-30°至+30°，GW级功率容量，满足Ku波段工作的系统指标与能力要求。对天线进行了实物加工与测试，测试结果说明该天线具有良好的波束扫描特性和较高的口径辐射效率。无需加载移相馈电网络便可改变波束指向，具有伺服简单，结构紧凑，平面化、低剖面、轻质等优点，可广泛应用于机载、车载、舰载等高功率微波系统的表面共形发射。Abstract: In this paper, a high power planar antenna without phase shifter is designed. This antenna realizes the function of space beam scanning through the phase distribution change of the aperture field via strata radiatum self-rotating, and realizes the requirements of light weight, and low profile integration. The gain of the antenna is 36 dB, the beam scanning range is from -30° to +30°, the power capability level is GW, the frequency range is Ku. We fabricated the antenna and tested its parameters, the results indicate that the antenna has high technical index in beam scanning and high aperture radiation efficiency. Compared with the traditional phased array antennae, this antenna can realize phase regulation, change the beam pointing without phase-shifted feed network, and it has the advantages such as simple servo, compact structure, low profile and low weight. This antenna can be applied to the surface conformal emission technique of the airborne, vehicular, shipboard high power weapon system.
-
表 1 天线测试结果
Table 1. Result of testing
frequency rceived power of measured antenna/dBm rceived power of standard antenna/dBm gain of standard antenna/dB gain of measured antenna/dB f-0.15 GHz 23.71 -36.80 23.33 36.42 f -23.32 -36.63 23.39 36.70 f+0.15 GHz -24.56 -37.46 23.48 36.38
下载: 导出CSV
-
[1] Balanis C A. Antenna theory: Analysis and design[M]. 3rd ed. New Jersey: John Wiley & Sons, 2001. [2] Milroy W W. Continuous transverse stub element devices and methods of making same: US5266961[P]. 1991-08-29. [3] Milroy W W. Continuous transverse stub element devices for flat plate antenna arrays: US5583524[P]. 1996-12-10. [4] 李相强, 刘庆想, 赵柳, 等. 高功率单层径向线螺旋阵列天线的设计与模拟[J]. 强激光与粒子束, 2005, 17(11): 1712-1716. http://www.hplpb.com.cn/article/id/2406Li Xiangqiang, Li Qingxiang, Zhaoliu, et al. High power helical array antenna fed from signal-layed radial waveguide. High Power Laser and Particle Beams, 2005, 17(11): 1712-1716 http://www.hplpb.com.cn/article/id/2406 [5] 李相强, 刘庆想, 赵柳, 等. 3圈48单元高功率径向线螺旋阵列天线研究[J]. 强激光与粒子束, 2006, 18(5): 843-846. https://www.cnki.com.cn/Article/CJFDTOTAL-QJGY200605033.htmLi Xiangqiang, Liu Qingxiang, Zhao Liu, et al. 3-ring-48-element high power radial line helical array antenna. High Power Laser and Particle Beams, 2006, 18(5): 843-846 https://www.cnki.com.cn/Article/CJFDTOTAL-QJGY200605033.htm [6] 刘庆, 张健穹, 刘庆想, 等. Ku波段28单元径向线阵列天线馈电系统设计[J]. 强激光与粒子束, 2016, 28: 033030. doi: 10.11884/HPLPB201628.033030Liu Qing, Zhang Jianqiong, Liu Qingxiang, et al. Design of Ku-band 28-element array-antenna radial line feed system. High Power Laser and Particle Beams, 2016, 28: 033030 doi: 10.11884/HPLPB201628.033030 [7] 李佳伟, 黄文华, 梁铁柱, 等. 基于漏波波导的X波段高功率微波天线[J]. 强激光与粒子束, 2011, 23(8): 2125-2129. http://www.hplpb.com.cn/article/id/5403Li Jiawei, Huang Wenhua, Liang Tiezhu, et al. Design and simulation of X-band HPM antenna based on leaky waveguide. High Power Laser and Particle Beams, 2011, 28(3): 2125-2129 http://www.hplpb.com.cn/article/id/5403 [8] 李佳伟, 黄文华, 张治强, 等. 基于漏波波导X波段高功率微波天线的实验[J]. 强激光与粒子束, 2011, 23(12): 3363-3366. http://www.hplpb.com.cn/article/id/5712Li Jiawei, Huang Wenhua, Zhang Zhiqiang, et al. Testing of an X-band HPM antenna based on leaky waveguide. High Power Laser and Particle Beams, 2011, 23(12): 3363-3366 http://www.hplpb.com.cn/article/id/5712 -
