Study of gamma irradiation effect on the 4H-SiC detector
-
摘要: 为研究4H-SiC探测器的抗γ辐照性能,使用40万Ci级的60Co源对4H-SiC探测器进行了数次辐照,累积辐照剂量最大为1 MGy(Si),并在辐照后对4H-SiC的性能进行了测试。随着累积辐照剂量增加,4H-SiC探测器的正向电流增大,而反向电流恰好相反;根据4H-SiC探测器的正向I-V曲线可提取理想因子和肖特基势垒,理想因子从1.87增加到2.18,肖特基势垒从1.93 V减小至1.69 V;4H-SiC探测器对241Am源产生的α粒子进行探测时,探测器的电荷收集率从95.65%退化到93.55%,测得能谱的能量分辨率由1.81%退化到2.32%。4H-SiC探测器在受到1 MGy(Si)的γ辐照后,与未受到辐照时相比,在探测能量为5.486 MeV的α粒子时能量分辨率和电荷收集率仅退化了28.18%和2.2%,仍具备优良的探测性能。Abstract: To investigate 4H-SiC detector’s resistance to gamma irradiation, the detector was irradiated by 60Co gamma-ray(about 4×105 Ci), and the maximum cumulative dose was 1 MGy. The detector’s I-V characteristics and its performance in detecting charged particles were tested after gamma irradiation. The forward current increased and the reverse current decreased as the cumulative dose was increased. The ideal factor and Schottky barrier height were extracted from forward I-V curves, and the result showed that ideal factor increased and Schottky barrier height decreased after irradiation. The detector was exposed to 241Am source, and it was found that the detector’s performance degraded slightly after gamma irradiation. However, the detector behaved well in detection after it received gamma exposures at a dose of 1 MGy: its charge collection efficiency was 93.55% and its energy resolution was 2.32% in detecting alpha particles of 5.486 MeV. Therefore it has been proved that 4H-SiC detector has good resistance to gamma irradiation.
-
Key words:
- 4H-SiC detector /
- gamma irradiation /
- I-V characteristics /
- alpha detector
-
表 1 辐照后器件的理想因子与肖特基势垒
Table 1. Ideal factor and Schottky barrier height after each irradiation
dose/Gy n φ/V 0 1.87 1.93 100 1.89 1.91 1000 1.89 1.91 100 000 1.97 1.81 1 000 000 2.18 1.69 表 2 α能谱的峰值、半高宽和能量分辨率及探测器的电荷收集率
Table 2. Peak centroid, FWHM, energy resolution of α energy spectra and charge collection efficiency (CCE) of the detector
dose/Gy peak centroid FWHM/keV energy resolution/% CCE/% 0 977.35 99.40 1.81 95.65 100 970.67 114.87 2.09 95.02 1000 968.27 123.52 2.25 94.79 100 000 963.73 115.15 2.10 94.36 1 000 000 955.23 127.37 2.32 93.55 -
[1] Sciortino S, Cindro V, Hartjes F, et al. Effect of heavy proton and neutron irradiations on epitaxial 4H-SiC Schottky diodes[J]. Nuclear Inst & Methods in Physics Research A, 2005, 552(1): 138-145. https://www.sciencedirect.com/science/article/pii/S0168900205011897 [2] Wu J, Lei J, Jiang Y, et al. Feasibility study of a SiC sandwich neutron spectrometer[J]. Nuclear Inst & Methods in Physics Research A, 2013, 708(708): 72-77. https://www.sciencedirect.com/science/article/pii/S016890021300065X [3] De Napoli M, Giacoppo F, Raciti G, et al. Study of charge collection efficiency in 4H-SiC Schottky diodes with 12C ions[J]. Nuclear Inst & Methods in Physics Research A, 2009, 608(1): 80-85. [4] Seshadri S, Dulloo A R, Ruddy F H, et al. Demonstration of an SiC neutron detector for high-radiation environments[J]. IEEE Trans Electron Devices Ed, 1999, 46(3): 567-571. doi: 10.1109/16.748878 [5] Park S H, Park J S, Seo H, et al. Development of SiC detector for the harsh environment applications[C]//IEEE Nuclear Science Symposium & Medical Imaging Conference. 2013. [6] Kalinina E V, Strokan N B, Ivanov A M, et al. 4H-Si Chigh temperature spectrometers[C]//Materials Science Forum. 2007. [7] Nava F, Vittone E, Vanni P, et al. Radiation tolerance of epitaxial silicon carbide detectors for electrons, protons and gamma-rays[J]. Nuclear Inst & Methods in Physics Research A, 2003, 514(1/3): 126-134. https://www.sciencedirect.com/science/article/pii/S0168900202015589 [8] Kinoshita A, Iwami M, Kobayashi K I, et al. Radiation effect on pn-SiC diode as a detector[J]. Nuclear Inst & Methods in Physics Research A, 2005, 541(1): 213-220. https://www.sciencedirect.com/science/article/pii/S0168900205000719 [9] 张林, 肖剑, 邱彦章, 等. Ti/4H-SiC肖特基势垒二极管抗辐射特性的研究[J]. 物理学报, 2011, 60: 056106. https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB201105083.htmZhang Lin, Xiao Jian, Qiu Yanzhang, et al. Radiation effect on Ti/4H-SiC SBD of gamma-ray, electrons and neutrons. Acta Physica Sinica, 2011, 60: 056106) https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB201105083.htm [10] 张林, 张义门, 张玉明, 等. Ni/4H-SiC肖特基势垒二极管的γ射线辐照效应[J]. 物理学报, 2009, 58(4): 2737-2741. https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200904096.htmZhang Lin, Zhang Yimen, Zhang Yuming, et al. Gamma-ray radiation effect on Ni/4H-SiC SBD. Acta Physica Sinica, 2009, 58(4): 2737-2741) https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200904096.htm [11] Table of radioisotopes in radiation safety reference manual[EB/OL]. https://www.vumc.org/safety/about/safety/safety/safety/rad. [12] Sze S M. Physics of semiconductor devices[M]. 2nd ed. New Jersey: Wiley, 1981. [13] Claeys C, Simoen E. 先进半导体材料及器件的辐射效应[M]. 北京: 国防工业出版社, 2008.Claeys C, Simoen E. Radiation effects in advanced semiconductor materials and devices. Beijing: National Defense Industry Press, 2008) [14] Kang S M, Ha J H, Park S H, et al. Study of the current-voltage characteristics of a SiC radiation detector irradiated by Co-60 gamma-rays[J]. Nuclear Instruments & Methods in Physics Research, 2007, 579(1): 145-147. https://www.sciencedirect.com/science/article/pii/S0168900207005967
