Vehicle cable electromagnetic pulse coupling simulation and suppression
-
摘要: 瞬态电磁脉冲可通过车辆互联线缆耦合至电子系统内部，造成电子设备受扰甚至损毁，研究瞬态防护器件对电磁脉冲的抑制特性可为车辆电磁防护设计与实施提供有力支撑。本文以发动机电控系统为研究对象，考虑关键金属结构、线缆与电子设备，建立发动机电磁仿真模型，计算获取了瞬态电磁脉冲作用下线缆端口耦合干扰特性；基于电磁脉冲注入方法设计并搭建了瞬态防护器件测试平台，获取了瞬态电压抑制器与压敏电阻两类典型瞬态防护器件的响应时间、钳位电压、尖峰泄露等响应特性；在仿真与测试结果的基础上，选取一型瞬态电压抑制器应用于凸轮轴位置传感器信号线的电磁防护。研究结果表明，该型瞬态电压抑制器对线缆瞬态电磁脉冲耦合干扰抑制能力接近20 dB，置于滤波器前端可有效抑制线缆耦合干扰，保护终端设备。Abstract: Transient electromagnetic pulses can be coupled to vehicle electronic system through cables, causing electronic equipment disturbance, even damage. Research on the suppression characteristics of transient protection devices on electromagnetic pulse can provide strong support for vehicle electromagnetic hardening. In this paper, we build the electromagnetic simulation model of vehicle engine by considering the key metal structure, cables and electronic equipment. Cables coupling characteristics were calculated under transient electromagnetic pulse; A test platform for transient protection devices was built, and the response characteristics of transient voltage suppress (TVS) and metal oxide varistor (MOV) were obtained, such as response time, clamping voltage, and peak voltage leakage. Based on the simulation and test results, a type of TVS was selected. This TVS is used to the signal line electromagnetic protection of camshaft position sensor. The result shows that this type of TVS has an ability of cable interference suppression close to 20 dB, and placing it in the front of filter can effectively suppress cable coupling interference and protect terminal equipment.
-
Key words:
- vehicle /
- cable coupling /
- electromagnetic pulse /
- transient protection device /
- protection efficiency
-
图 11 TVS对凸轮轴位置传感器信号线耦合抑制
Figure 11. Camshaft position sensor signal cable coupling suppress of PCI
表 1 受试瞬态器件型号
Table 1. Transient device under test
type model MOV V130LA1P VGAH121026H560 TVS 1.5KE27CA TP5.0SMDJ15A
下载: 导出CSV
表 2 瞬态器件EFT响应特性对比
Table 2. Transient device response character under EFT
No. response time@4 kV/ns clamping voltage@4 kV/V leakage voltage peak value@4 kV/V V130LA1P 6.4 356.0 558.4 VGAH121026H560 6.3 82.4 129.0 1.5KE27CA 3.2 44.3 372 TP5.0SMDJ15A 4.7 16.5 49.3
下载: 导出CSV
表 3 不同电压下TVS抑制效果
Table 3. TVS suppression efficiency under different PCI peak value
PCI set voltage/kV cable coupling peak voltage/V peak leakage voltage/V suppression efficiency/dB 5 686 90 17.6 10 1360 202 16.6 16 2213 435 14.1
下载: 导出CSV
-
[1] Radasky W A, Baum C E, Wik M W. Introduction to the special issue on high-power electromagnetics (HEMP) and intentional electromagnetic interference (IEMI)[J]. IEEE Transactions on Electromagnetic Compatibility, 2004, 46(3): 314-321. doi: 10.1109/TEMC.2004.831899 [2] 李名杰, 刘进. 电子装备面临的强电磁脉冲环境分析[J]. 装备环境工程, 2012, 9(2):69-73. (Li Mingjie, Liu Jin. Environmental analysis of high power EMP on electronic equipment[J]. Equipment Environmental Engineering, 2012, 9(2): 69-73 doi: 10.3969/j.issn.1672-9242.2012.02.017 [3] Savage E, Radasky W. Overview of the threat of IEMI (intentional electromagnetic interference)[C]//Proc IEEE Int Symp on Electromagn Compat. 2012: 317-322. [4] Camp M, Garbe H. Susceptibility of personal computer systems to fast transient electromagnetic pulses[J]. IEEE Transactions on Electromagnetic Compatibility, 2006, 48(4): 829-833. doi: 10.1109/TEMC.2006.882844 [5] Stefan V B, Frank L. Vulnerability of remote keyless-entry systems against pulsed electromagnetic interference and possible improvements[J]. IEEE Transactions on Electromagnetic Compatibility, 2016, 58(4): 1259-1265. doi: 10.1109/TEMC.2016.2570303 [6] Bohl J, Stark R H, Wollman G. RF weapons for non-lethal interference and destruction of communication, information and electronic systems[C]//Proc 2nd European Workshop on Survivability. 2004. [7] 蔡金良, 孙晓颖, 赵晓晖. 考虑复杂金属设备的车辆发动机舱电磁环境效应分析[J]. 吉林大学学报(工学版), 2016, 46(4):1360-1367. (Cai Jinliang, Sun Xiaoying, Zhao Xiaohui. Electromagnetic environment effects for automotive engine block with complex metallic equipment[J]. Journal of Jilin University (Engineering and Technology Edition), 2016, 46(4): 1360-1367 [8] 郑浩月, 贺志昂, 宋滔, 等. 车辆平台电磁安全威胁量化分析[J]. 通信技术, 2019, 52(2):460-465. (Zheng Haoyue, He Zhiang, Song Tao, et al. Quantitative analysis of electromagnetic safety threats on vehicle platforms[J]. Communications Technology, 2019, 52(2): 460-465 doi: 10.3969/j.issn.1002-0802.2019.02.034 [9] 王震, 蔡金良, 秦风, 等. 汽车发动机转速传感器瞬变脉冲敏感性研究[J]. 强激光与粒子束, 2020, 32:083003. (Wang Zhen, Cai Jinliang, Qin Feng, et al. Susceptibility of automotive engine speed sensor to transient electromagnetic pulse[J]. High Power Laser and Particle Beams, 2020, 32: 083003 [10] 孙晓颖, 王震, 杨锦鹏, 等. 基于贝叶斯网络的电子节气门电磁敏感性评估[J]. 吉林大学学报(工学版), 2018, 48(1):281-289. (Sun Xiaoying, Wang Zhen, Yang Jinpeng, et al. Electromagnetic susceptibility assessment of electronic throttle based on Bayesian network[J]. Journal of Jilin University (Engineering and Technology Edition), 2018, 48(1): 281-289 [11] 李慧梅, 唐彦峰, 刘祥凯, 等. 电磁脉冲武器对车辆装备的损伤效应研究[J]. 装备环境工程, 2010, 7(3):31-34. (Li Huimei, Tang Yanfeng, Liu Xiangkai, et al. Study of destructive effects of electromagnetic pulse weapon on vehicle[J]. Equipment Environmental Engineering, 2010, 7(3): 31-34 doi: 10.3969/j.issn.1672-9242.2010.03.008 [12] 秦风, 蔡金良, 曹学军, 等. 车辆强电磁脉冲环境适应性研究[J]. 强激光与粒子束, 2019, 31:103203. (Qin Feng, Cai Jinliang, Cao Xuejun, et al. Investigation on the adaptability of vehicle in high-intensity electromagnetic pulse environment[J]. High Power Laser and Particle Beams, 2019, 31: 103203 doi: 10.11884/HPLPB201931.190233 [13] Yang S H, Tang Y F, Liu X K, et al. Study on effects of high-altitude electromagnetic pulse to engine electronic control system[J]. Advanced Materials Research, 443/444: 894-898. [14] Hobbins K A W. EMP and transient suppressed mains filters[C]//Seventh International Conference on Electromagnetic Compatibility. 1990. [15] 张希军, 杨洁, 张庆海. 瞬态电压抑制器在快上升沿电磁脉冲作用下的瞬态响应[J]. 高电压技术, 2012, 38(9):2242-2247. (Zhang Xijun, Yang Jie, Zhang Qinghai. Transient response of transient voltage suppressor device under EMP with fast rise time[J]. High Voltage Engineering, 2012, 38(9): 2242-2247 [16] 马浪凯. 强电磁脉冲下传导防护器件瞬态响应特性研究[D]. 西安: 西安电子科技大学, 2018.Ma Langkai. Research on transient response characteristics of conductive protection device under strong electromagnetic pulse. Xi’an: Xidian University, 2018 [17] GJB 8848-2016, 系统电磁环境效应试验方法[S].GJB 8848-2016. Electromagnetic environmental effects test methods for systems. 2016 -
