Design of high voltage pulse generator based on resonant circuit and pulse transformer
-
摘要: 提出一种基于谐振电路与脉冲变压器结合的高压脉冲实现方案，该方案利用电容与电感的谐振效应，结合脉冲变压器的升压作用，在仅使用一个半导体开关的条件下，实现高压脉冲的输出，其结构简单，成本低，并且可实现零电压关断。并对于电路的运行模式进行了理论分析，搭建了原理样机进行实验。容性负载条件下，实现频率1～ 15 kHz、幅值0～ 10 kV可调的高压脉冲输出，对比分析了续流支路以及续流电阻对于输出高压脉冲波形的影响。利用该脉冲电源进行DBD放电实验，成功驱动介质阻挡放电反应器，验证了该方案的可行性。Abstract: Low temperature plasma excited by dielectric barrier discharges (DBDs) is widely used in medical health, air purification and other fields, and DBDs are commonly driven by high voltage pulse generators. In this paper, a high voltage pulse generator based on the combination of resonant circuit and pulsed transformer is proposed. The circuit uses the resonant effect of capacitor and inductor, combined with boost effect of pulsed transformer, and only one semiconductor switch to output high voltage pulses. The structure is simple, the cost is low, and zero voltage switching (ZVS) can be realized. In this paper, the operation mode of the circuit is analyzed theoretically, and the prototype is built for experiment. Under the condition of capacitive load, high voltage pulses with adjustable frequency of 1−15 kHz and amplitude of 0−10 kV are generated , and the influence of freewheeling branch and freewheeling resistance on the output high-voltage pulse waveform is analyzed. The DBD discharge experiment was carried out by using the pulse generator, and the DBD reactor was successfully driven, which further verified the feasibility of the circuit.
-
Key words:
- resonant circuit /
- pulse generator /
- pulsed transformer /
- dielectric barrier discharge
-
图 8 不同频率下续流支路对输出高压脉冲波形影响
Figure 8. Influence of freewheeling branch on output high voltage pulse waveform at different frequencies
图 9 不同续流电阻Rp下的原边电流Ip和输出电压Vo波形
Figure 9. Primary current Ip and output voltage waveform under different freewheeling resistance Rp
表 1 实验参数
Table 1. Experimental parameters
Vdc/V Lr /µH Cr/nF Lleakage/ µH Lm/mH Rp/ Ω transformer turn ratio Cout/pF 70 36 110 12 2.8 8 12∶800 10
下载: 导出CSV
-
[1] Guven A, Gundogdu G, Vurucu S, et al. Medical ozone therapy reduces oxidative stress and intestinal damage in an experimental model of necrotizing enterocolitis in neonatal rats[J]. Journal of Pediatric Surgery, 2009, 44(9): 1730-1735. doi: 10.1016/j.jpedsurg.2009.01.007 [2] Tepper G, Kessick R, Pestov D. An electrospray-based, ozone-free air purification technology[J]. Journal of Applied Physics, 2007, 102: 113305. doi: 10.1063/1.2818364 [3] Bicknell D, Jain R. Ozone disinfection of drinking water - technology transfer and policy issues[J]. Environmental Engineering and Policy, 2001, 3(1): 55-66. doi: 10.1007/s100220100043 [4] Johnson C J, Singer P C. Impact of a magnetic ion exchange resin on ozone demand and bromate formation during drinking water treatment[J]. Water Research, 2004, 38(17): 3738-3750. doi: 10.1016/j.watres.2004.06.021 [5] 李昊, 周律, 李涛, 等. 臭氧氧化法深度处理印染废水生化处理出水[J]. 化工环保, 2012(1):30-34. (Li Hao, Zhou Lü, Li Tao, et al. Advanced treatment of bio-treated dyeing wastewater by ozone oxidation process[J]. Environment Protection of Chemical Industry, 2012(1): 30-34 doi: 10.3969/j.issn.1006-1878.2012.01.007 [6] 冯卫强, 刘振, 刘百良, 等. 双极性脉冲臭氧发生的实验研究[J]. 高电压技术, 2018, 44(9):3083-3088. (Feng Weiqiang, Liu Zhen, Liu Bailiang, et al. Experimental study of ozone generation by using bipolar pulse power supply[J]. High Voltage Engineering, 2018, 44(9): 3083-3088 [7] 商克峰, 王美威, 鲁娜, 等. 沿面/体介质阻挡放电装置的放电及臭氧生成特性[J]. 高电压技术, 2021, 47(1):353-359. (Shang Kefeng, Wang Meiwei, Lu Na, et al. Discharge characteristics and ozone generation of surface/volume hybrid dielectric barrier discharge devices[J]. High Voltage Engineering, 2021, 47(1): 353-359 [8] 史曜炜, 周若瑜, 崔行磊, 等. 不同电源激励下共面介质阻挡放电特性实验[J]. 电工技术学报, 2018, 33(22):5371-5380. (Shi Yaowei, Zhou Ruoyu, Cui Xinglei, et al. Experimental investigation on characteristics of coplanar dielectric barrier discharge driven by different power supplies[J]. Transactions of China Electrotechnical Society, 2018, 33(22): 5371-5380 [9] 刘克富. 固态Marx发生器研究进展[J]. 高电压技术, 2015, 41(6):1781-1787. (Liu Kefu. Research progress in solid-state Marx generators[J]. High Voltage Engineering, 2015, 41(6): 1781-1787 [10] Rao Junfeng, Lei Yang, Jiang Song, et al. All solid-state rectangular sub-microsecond pulse generator for water treatment application[J]. IEEE Transactions on Plasma Science, 2018, 46(10): 3359-3363. doi: 10.1109/TPS.2018.2829206 [11] Zhou Ziwei, Zi Li, Rao Junfeng, et al. A high-performance drive circuit for all solid-state Marx generator[J]. IEEE Transactions on Plasma Science, 2016, 44(11): 2779-2784. doi: 10.1109/TPS.2016.2577704 [12] Redondo L M, Silva J. Repetitive high-voltage solid-state Marx modulator design for various load conditions[J]. IEEE Transactions on Plasma Science, 2009, 37(8): 1632-1637. doi: 10.1109/TPS.2009.2023221 [13] Rai S, Tandon P, Jangid S, et al. A trigger system with high voltage isolation for multiple switching devices[J]. International Journal of Electronics and Communication Engineering & Technology (IJECET), 2013, 4(7): 155-162. [14] Canacsinh H, Redondo L M, Silva J F. Isolated autonomous capacitive power supplies to trigger floating semiconductors in a Marx generator[C]//IEEE International Symposium on. Industrial Electronics. 2007. [15] Zhao Min, Zhou Xing, Wang Qingguo, et al. Design of miniature dual exponential pulse source using EMC experiment[J]. Advanced Materials Research, 2014, 926/930: 407-410. doi: 10.4028/www.scientific.net/AMR.926-930.407 [16] 饶俊峰, 曾彤, 李孜, 等. 固态Marx发生器的过流保护研究[J]. 强激光与粒子束, 2019, 31:125001. (Rao Junfeng, Zeng Tong, Li Zi, et al. Study on over-current protection of solid-state Marx generators[J]. High Power Laser and Particle Beams, 2019, 31: 125001 doi: 10.11884/HPLPB201931.190138 [17] Li Zi, Liu Haotian, Rao Junfeng, et al. Gate driving circuit for the all solid-state rectangular Marx generator[J]. IEEE Transactions on Plasma Science, 2019, 47(8): 4058-4063. doi: 10.1109/TPS.2019.2923327 [18] 冯卫强. 脉冲臭氧发生器的研制及其在烟气治理中的应用[D]. 杭州: 浙江大学, 2017Feng Weiqiang. Development of pulse ozone generator and its application in flue gas treatment[D]. Hangzhou: Zhejiang University, 2017 [19] You Changqi, Wang Mengqi, Ye J. An isolated high-voltage high-frequency pulsed power converter for non-thermal plasma ozone generation[C]//IEEE Energy Conversion Congress and Exposition (ECCE). 2017. [20] 饶俊峰, 吴改生, 王永刚, 等. 采用单开关谐振电路的脉冲电源设计[J]. 强激光与粒子束, 2020, 32:085001. (Rao Junfeng, Wu Gaisheng, Wang Yonggang, et al. Design of pulsed power supply using single switch resonant circuit[J]. High Power Laser and Particle Beams, 2020, 32: 085001 doi: 10.11884/HPLPB202032.200163 [21] 刘星亮, 邱祁, 王若宇, 等. 基于有限元仿真的高频高压变压器分段绕组漏感设计方法[J]. 高电压技术, 2020, 46(2):610-617. (Liu Xingliang, Qiu Qi, Wang Ruoyu, et al. Design method for leakage inductance of high-frequency high-voltage transformer with winding segmented based on finite element simulation[J]. High Voltage Engineering, 2020, 46(2): 610-617 [22] Somekawa T, Shirafuji T, Sakai O, et al. Effects of self-erasing discharges on the uniformity of the dielectric barrier discharge[J]. Journal of Physics D Applied Physics, 2005, 38(12): 1910-1917. doi: 10.1088/0022-3727/38/12/010 -
