40 kW高功率密度数字化控制充电电源
40 kW digital control capacitor charging power supply
-
摘要: 研制了基于串联谐振和高频逆变技术的40 kW/10 kV数字化控制高频高压脉冲电容器恒流充电电源；采用合理谐振参数设计和高频高压变压器优化设计，使得40 kW充电电源功率密度达到0.5 MW/m3；研究了高压充电电源的保护技术，通过采取多种保护方法及安全措施，提高了充电电源的安全性能；在40 kW数字化控制充电电源基础上，介绍了实现充电电源远端控制和并联运行的方案；给出了1 MJ/10 kV脉冲电容器负载上的单台充电电源的实验结果。Abstract: A compact 40 kW/10 kV digital control constant-current capacitor charging power supply(CCPS )has been developed based on the series resonance and high frequency inverter technologies. The logical design of resonant parameters and the high frequency high voltage transformer was adopted and the power density of 0.5 MW/m3 was achieved. The protection technology of the CCPS was studied, and the performance of the CCPS was improved by using multiple protecting techniques and safeguards. A scheme of remote control and parallel operation of the power supply was introduced. Some experimental results were given with a 1 MJ/10 kV capacitive load.
-
Key words:
- high frequency /
- high voltage /
- series resonance /
- inverter /
- capacitor charging power supply /
- miniaturization
-
