100 kA快脉冲直线变压器驱动源模块
Research on 100 kA fast linear transformer driver stage
-
摘要: 介绍了100 kA快脉冲直线变压器驱动源原型模块及其采用的200 kV多级多通道气体开关的设计和初步实验结果。该模块由20台100 kV/20 nF电容器按10个支路并联组成，其中每个支路包括2台电容器、1只多级多通道开关以及相应的传输线。模块直径约1.5 m，厚度仅为20 cm。采用B-dot探针诊断负载电流。当充电电压为±90 kV时，在1.1 Ω负载上可得到102.2 kA的峰值电流，上升时间为53.6 ns，脉冲宽度为133 ns。实验结果表明，该快脉冲直线变压器驱动源模块具有较好的快脉冲输出能力。
-
关键词:
- 快脉冲直线变压器驱动源 /
- 多级多通道开关 /
- 抖动 /
- 磁芯 /
- B-dot探针
Abstract: This paper describes the design and test results of an liner transformer driver(LTD) stage prototype and its multi-gap switch. This stage consists of 20 storage capacitors(100 kV/20 nF) that are arranged in 10 identical bricks locating evenly around the axis of the stage. Each brick contains two capacitors, a multi-gap switch, and the output connector that transfer the energy to the resistive load. The outer diameter of the stage is about 1.5 m, at a thickness of 20 cm. The load current was measured by B-dot probe. The magnetic core was premagnetized before each shot. At the charge voltage of ±90 kV, the stage can deliver 102.2 kA fast pulse with a FWHM of 133 ns into a 1.1 Ω resistive load. The experimental results show that the LTD stage has the capability of fast pulse output.-
Key words:
- fast linear transformer driver /
- multi-gap switch /
- jitter /
- magnetic core /
- b-dot probe
-
