40 GW重复频率脉冲驱动源研制进展
Progress on a 40 GW repetitive pulsed accelerator
-
摘要: 40 GW重复频率脉冲驱动源是应高功率微波技术发展等需求而设计的一台基于Tesla变压器技术的重复频率脉冲功率装置。40 GW驱动源设计输出功率40 GW，脉宽60 ns，重复频率1~50 Hz，输出功率及重复频率工作状态在一定范围内可调。介绍了40 GW高功率重复频率脉冲驱动源的系统构成、电气及结构参数的确定方法、关键部件的工程工艺技术，并分析了关键绝缘部件的电场分布。已完成驱动源安装并进行了实验调试，其主要单元Tesla变压器的能量效率达到70%，驱动源单次工作状态下输出功率大于40 GW；50 Hz重复频率工作状态下，输出功率20.6 GW，系统工作稳定可靠。Abstract: Development of 40 GW repetitive pulsed driver is summarized in this report. The output of the 40 GW repetitive pulsed driver source is aimed to exceed 40 GW, the pulse width is about 60ns, and the range of repetition rate is set from 1 pps to 50 pps. Based on the Tesla technology, the general design of the 40 GW driver source is described. The accelerator was assembled and an experiment was performed for generating high power microwave. For charging the forming line, a Tesla transformer with open magnetic core was used, a high efficiency about 70% of the transformer was achieved by means of optimization. As an electron beam source, the output of the 40 GW driver source is more than 40 GW. With 50 Hz repetition rate, the mean power of the diode has exceeded 20 GW. Operation experiments have
-
Key words:
- pulse power technology /
- repetitive frequency /
- tesla transformer /
- high voltage /
- intense current
-
