Researches and applications of X-ray high-spatial-resolution multi-energy microscope system
-
摘要: 在激光间接驱动惯性约束聚变（ICF）领域中，获得具有极高空间分辨率（优于5 m）的X射线辐射图像，是研究烧蚀不稳定性、内爆流线等关键物理过程的数据基础。基于掠入射反射式成像原理的Kirkpatrick-Baez(KB)显微成像系统作为一种具有高空间分辨率和集光效率的X射线显微诊断设备，目前已成为国际ICF装置的X射线关键诊断设备。在神光Ⅱ和神光Ⅲ原型装置条件上开展了KB诊断技术及设备的研究，在KB系统的光学设计、光学元件和物镜与系统装调技术等方面取得了许多重要进展，研制了大视场KB、多色KB等高分辨率X射线显微成像系统。这些系统已应用于我国的ICF内爆芯部发光和流线测量、流体不稳定增长测量等实验中，为关键物理量的测量提供了高空间分辨率的清晰图像。
-
关键词:
- Kirkpatrick-Baez显微镜 /
- 高空间分辨 /
- 等离子体诊断 /
- 惯性约束聚变
Abstract: In the field of indirect-drive inertial-confinement-fusion, to acquire high spatial resolution X-ray radiation images is the foundation for hydrodynamic instabilities and imploded process researches. Kirkpatrick-Baez (KB) microscope, which is based on the principles of grazing-incidence X-ray imaging, is an X-ray diagnosis device presenting an extra-high spatial resolution and a big total solid angle of collection. The KB microscope has been an international key X-ray diagnosis device on ICF facilities. We have investigated KB devices on SG-Ⅱ and SG-Ⅲ prototype facilities and made remarkable progresses on optical design, optical component preparation and assemblage technology of objective mirrors. A large object-field KB microscope and a multi-energy KB microscope have been developed. These KB microscopes have been applied in the hydrodynamic instabilities and implosion experiments, and performed high-resolution high-magnification images of key physical data for laser-fusion plasma research. -
