氮化铝双端固支音叉谐振器的结构设计

雷强; 高杨; 赵俊武; 吕军光

doi:10.11884/HPLPB201729.170113

氮化铝双端固支音叉谐振器的结构设计

doi: 10.11884/HPLPB201729.170113

1.
西南科技大学信息工程学院, 四川绵阳 621 01 0;
2.
中国工程物理研究院电子工程研究所, 四川绵阳 621 999;
3.
中国科学院高能物理研究所, 核探测与核电子学国家重点实验室, 北京 1 00049

计量
- 文章访问数: 888
- HTML全文浏览量: 146
- PDF下载量: 229
- 被引次数: 0
出版历程
- 收稿日期: 2017-04-07
- 修回日期: 2017-09-04
- 刊出日期: 2017-10-15

Structure design of aluminium nitride double-ended tuning fork resonators

1.
School of Information Engineering,Southwest University of Science and Technology,Mianyang 621010,China;
2.
Institute of Electronic Engineering,China Academy of Engineering Physics,Mianyang 621999,China;
3.
State Key Laboratory of Particle Detection and Electronics,Institute of High Energy Physics,Chinese Academy of Sciences,Beijing 100049,China

摘要

摘要: 基于氮化铝双端固支音叉（AlN DETF）的谐振式传感器具有尺寸小、稳定性和可靠性好、时间响应快等特点。为了提高灵敏度和分辨率，需要分析AlN DETF谐振器的振梁结构参数对灵敏度和信号功率的影响。在有限元仿真软件中建立AlN谐振器的多物理场模型，进行预应力特征频率分析，仿真验证单个振梁结构参数对灵敏度的影响。在振梁厚度保持恒定的情况下，对仿真结果的数据进行后处理，得到信号功率与振梁长度、宽度的关系。结果表明，相对灵敏度、信号功率随振梁长度、宽度的变化趋势相反。因此，需要根据工艺水平和结构强度等因素，综合考虑AlN谐振器的信号功率和相对灵敏度，对两者进行权衡。仿真分析了优化后AlN DETF谐振器的性能，10 N范围内的灵敏度为56 Hz/N，信号功率为6.810-4 nW，Q值为958。
- 微传感器 /
- 氮化铝双端固支音叉 /
- 灵敏度 /
- 信号功率
Abstract: The resonant sensors based on aluminum nitride double-ended tuning fork (AlN DETF) have the characteristics of small size, good stability and reliability, and fast response. In order to improve the sensitivity and resolution, it is necessary to analyze the influence of the structure parameters of vibrating beam on the sensitivity and signal power of AlN resonator. The multi-physics model of AlN DETF resonator was established to verify effect of single parameter on the sensitivity by pre-stressed eigenfrequency analysis. The relationships between signal power and length, width of vibrating beam were obtained by post-processing data of simulation results when the thickness remained constant. The results show that relative sensitivity and signal power are growing in opposite directions with the width or the length of the beam. Therefore, there is a design tradeoff between signal power and relative sensitivity of AlN resonator according to process and structure strength. The optimized AlN DETF resonator was simulated, and its sensitivity, signal power and Q value are 56 Hz/N, 6.810-4 nW and 958, respectively.
- micro-sensor /
- aluminum nitride double-ended tuning fork /
- sensitivity /
- signal power
