Intrinsic emittance of thermal cathode with radial temperature variation
-
摘要: 从热发射理论出发，推导了非均匀发射阴极的均方根本征发射度的一般计算形式。针对一种最常见的温度径向分布近似模型，给出了均方根发射度随温度非均匀性变化趋势的理论数值解。基于有限差分法粒子仿真技术统计了热阴极的本征发射度，仿真结果与理论解一致，验证了非均匀发射热阴极本征均方根发射度一般形式的正确性。结果表明，径向温度非均匀性引起均方根发射度显著变化，非均匀系数为10%时引起均方根发射度下降约15%。本文建立的理论形式和仿真方法可以有效评估束流品质控制目标和工程热设计之间的依赖关系，以指导高效费比的工程设计。
-
关键词:
- 热阴极 /
- 有限差分电磁场粒子仿真 /
- 本征发射度 /
- 温度非均匀性 /
- 阴极寿命
Abstract: Thermionic cathode is widely used in accelerators, FELs and all kinds of vacuum electronics. For better performance and long stable running, low emittance with notable contribution from cathode is needed. Emittance of perfect thermal cathode only depends on radius and temperature. However, emission non-uniformity exists due to cathode surface profile, material distribution, temperature variation, crystal orientation, etc., which may cause intrinsic emittance growth, brightness decline, envelop size augment, device performance deterioration or even failure. To understand how intrinsic emittance is manipulated by temperature variation, a general intrinsic emittance model consisting of contributions from surface non-uniformity is developed based on general thermal emission. Numerical calculation for a cathode with radial temperature variation shows that RMS emittance declines about 15% when non-uniformity reaches 10%, which well conforms to FDTD-PIC simulation result.-
Key words:
- thermionic cathode /
- FDTD-PIC /
- intrinsic emittance /
- temperature variation /
- cathode lifetime
-
图 4 均匀发射和实际径向非均匀发射的x-vx相空间分布
Figure 4. x-vx phase space of uniform and practical emission
-
[1] Pedersen A, Manolescu A, Valfells A. Space-charge modulation in vacuum microdiodes at THz frequencies[J]. Physical Review Letters, 2010, 104 : 175002. [2] Jensen K L, Shiffler D A, Petillo J J, et al. Emittance, surface structure, and electron emission[J]. Phys Rev St Accel Beams, 2014, 17 : 043402. [3] 程诚, 程道喜, 郑曙昕, 等. 新型热阴极电子枪加热结构热分析[J]. 强激光与粒子束, 2010, 22 (7): 1607-1609. http://www.hplpb.com.cn/article/id/4360Cheng Cheng, Cheng Daoxi, Zheng Shuxin, et al. Thermal analysis of heating structure for thermionic cathode electron gun. High Power Laser and Particle Beams, 2010, 22 (7): 1607-1609 http://www.hplpb.com.cn/article/id/4360 [4] Zhang Dezheng. Microscopic study of TWT cathode. Chengdu: University of Electronic Science and Technology of China, 2007: 6-7 [5] Jensen K L, Lau Y Y, Nicholas, et al. Emission nonuniformity due to profilimetry variation in thermionic cathodes[J]. Appl Phys Lett, 2006, 88 : 164105. [6] Simmons D F, Fortgang C M, Holtkamp D B. Using multispectral imaging to measure temperature profiles and emissivity of large thermionic dispenser cathodes[J]. Review of Scientific Instruments, 2001, 76 : 044901. [7] 林祖伦, 王小菊. 阴极电子学[M]. 北京: 国防工业出版社, 2013: 5-15.Lin Zulun, Wang Xiaoju. Cathode electronics. Beijing: National Defense Industry Press, 2013: 5-15 [8] 周俊. 电磁粒子模拟方法及其应用研究[D]. 成都: 电子科技大学, 2009: 18-94.Zhou Jun. Research on electromagnetic particle simulation method and its application. Chengdu: University of Electronic Science and Technology of China, 2009: 18-94 [9] 张振海, 宋忠恒. 束流均方根发射度和边缘发射度[J]. 强激光与粒子束, 1991, 3 (4): 519-524. https://www.cnki.com.cn/Article/CJFDTOTAL-QJGY199104016.htmZhang Zhenhai, Song Zhongheng. The RMS emittance and marginal emittance of particle beams. High Power Laser and Partice Beams, 1991, 3 (4): 519-524 https://www.cnki.com.cn/Article/CJFDTOTAL-QJGY199104016.htm -
