Structure design and optimization of a dump beam window

Nie Xiaojun^{1, 2
,},
Liu Lei^{1, 2},
Kang Ling^{1, 2},
Chen Jiaxin^{1, 2},
Wang Anxin^{1, 2},
Yu Jiebing^{1, 2},
He Huayan^{1, 2},
Zhu Donghui^{1, 2}

1.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
2.
Dongguan Neutron Science Center, Dongguan 523803, China

摘要

摘要: 废束站束窗是废束站的重要部件。利用束流的束斑尺寸及功率确定束窗能量的高斯分布方式；通过蒙特卡罗方法计算束窗的沉积能量。利用ANSYS稳态分析确定束窗的材料、截面形状和厚度。通过计算比较束窗在不同材料、截面形状和厚度条件下的温度、应力和变形，得出合适的束窗材料、截面形状和厚度，从而确定束窗的最终结构。最后利用瞬态方法模拟束窗调束时的温度分布情况。
- 废束站束窗 /
- 蒙特卡洛方法 /
- 稳态分析 /
- 束窗结构 /
- 瞬态分析
Abstract: Dump beam window is an important part of the dump. The Gaussian distribution of energy was decided by the beam size and power. The energy deposition was calculated by the Monte Carlo method. The thermal steady-state analysis of ANSYS was applied to decide the material, section shape and thickness of the dump beam window. The temperature, stress and deformation with different materials, section shapes and thickness were analyzed and compared to get the suitable material, section shape and thickness for the dump beam window. The final structure of the dump beam window was decided accordingly and the temperature of the window was simulated by the transient analysis of ANSYS.
- dump beam window /
- Monte Carlo method /
- steady-state analysis /
- structure of beam window /
- transient analysis

HTML全文

图 1 废束站INDUMP束窗表面束流能量分布

Figure 1. Distribution of beam energy on the surface of INDUMP window

下载: 全尺寸图片幻灯片

图 2 三种束窗截面形状

Figure 2. Three alternative section shapes for the INDUMP beam window

下载: 全尺寸图片幻灯片

图 3 束窗散热结构优化

Figure 3. Cooling structure optimization for the INDUMP beam window

下载: 全尺寸图片幻灯片

图 4 束窗温度(厚度2 mm)

Figure 4. Distribution of temperature for the 2 mm INDUMP beam window

下载: 全尺寸图片幻灯片

图 5 应力分布(厚度2 mm)

Figure 5. Distribution of stress for the 2 mm INDUMP beam window

下载: 全尺寸图片幻灯片

图 6 变形分布(厚度2 mm)

Figure 6. Distribution of deformation for the 2 mm INDUMP beam window

下载: 全尺寸图片幻灯片

图 7 束窗瞬态温度曲线(厚度2 mm)

Figure 7. Transient temperature curve for the 2 mm INDUMP beam window

下载: 全尺寸图片幻灯片

表 1 废束站INDUMP束流参数

Table 1. Beam parameters of INDUMP

beam power/kW	beam energy/MeV	beam size/mm	pulse width/ms	frequency/Hz
2.0	80	(x: 51, y: 22)	0.4	25

下载: 导出CSV

表 2 几种束窗材料能量损失

Table 2. Energy loss of the materials for the dump window

material	energy loss Q/W
Inconel718	513.94
Glidcop^® AL-15	552.87
316L	482.42
Ti-6Al-4V	278.62
A5083	181.78

下载: 导出CSV

表 3 几种束窗材料的最高温度、最大应力和变形

Table 3. The highest temperature, stress and deformation for the alternative materials of the beam window

material	highest temperature/℃	highest stress/MPa	deformation in the center/mm	melting point/℃	yield limit/MPa
Inconel718	6995	-	-	1260-1336	1100
Glidcop^® AL-15	766	301	1.35	1082	255-300
316L	4824	-	-	1370-1400	290
Ti-6Al-4V	6086	-	-	1604-1660	880
A5083	431	200	1.62	590.6-638	190

下载: 导出CSV

表 4 三种截面束窗的最高温度、最大应力和变形

Table 4. The highest temperature, stress and deformation for the three alternative section shapes of the INDUMP beam window

section shape	highest temperature/℃	highest stress/MPa	deformation in the center/mm
spherical inside convex	769	301	1.35
spherical outside convex	766	311	3.30
planar	788	385	2.00

下载: 导出CSV

表 5 束窗不同厚度的能量损失及温度受力情况

Table 5. Energy loss, temperature and stress status for different thickness of the INDUMP beam window

window thickness/mm	energy loss/W	highest temperature/℃	highest stress/MPa	deformation in the center/mm
1.0	200.85	294	166	0.11
1.5	309.21	343	208	0.34
2.0	423.25	394	251	0.95
2.5	546.94	450	290	1.55
3.0	692.44	519	336	1.92

下载: 导出CSV
