一种中能辐射照相降散射网栅的改进及验证

刘文杰; 景越峰; 刘军; 宋科峰; 陈坤

doi:10.11884/HPLPB201830.180216

一种中能辐射照相降散射网栅的改进及验证

doi: 10.11884/HPLPB201830.180216

中国工程物理研究院流体物理研究所, 四川绵阳 621900

基金项目:

国家自然科学基金项目 21677134

详细信息

作者简介:
刘文杰(1982—)，男，博士，副研究员，主要从事X光照相技术方面的研究；wjliu@caep.cn

通讯作者:
宋科峰(1982—)，男，博士，助理研究员，主要从事X光照相模拟研究；skyvisitor@126.com

陈坤(1987—)，男，博士，助理研究员，主要从事X光照相技术实验研究；chenkun@caep.cn

中图分类号: O434.19
计量
- 文章访问数: 955
- HTML全文浏览量: 244
- PDF下载量: 76
- 被引次数: 0
出版历程
- 收稿日期: 2018-08-11
- 修回日期: 2018-11-04
- 刊出日期: 2018-12-15

Improving and testing of anti-scatter grid for medium-energy radiography

Institute of Fluid Physics, CAEP, Mianyang 621900, China

摘要

摘要: 为提高中能闪光照相实验能力，给高能闪光照相的网栅设计制造提供新的思路，结合前期2 mm厚网栅降散射的研究成果，通过同时考虑网栅投射立体角的有阻挡和无阻挡部分，分析了不同光子能量下网栅厚度对降散射效果的影响，并设计制造了一种具有更高网栅比的网栅。采用100 kV光源对空心球体成像的实验验证其降散射效果，结果表明，网栅使图像对比度获得近1倍提升。采用实际的实验布局作为输入开展了蒙特卡罗模拟，验证比较了新设计网栅降散射效果，其降散射比高达1000∶1。
- X射线光学 /
- 中能辐射照相 /
- 降散射网栅 /
- 蒙特卡罗模拟
Abstract: In this work an anti-scatter grid with higher grid ratio was designed and fabricated based on our previous 2mm grid studies. To clarify the influence of grid thickness and phonon energy on scattering reduction, the acceptance solid angle of a single grid hole was analyzed carefully, where both blocked and unblocked ray were considered. A radiographic experiment and a Monte Carlo simulation were conducted to verify the performance of the grid. Results indicate the contrast of image was nearly doubled when a grid was used. Scatter rejection of the grid was estimated to be at least 1000∶1, which is high enough to suppress most of the scatterings in various application scenes. Results in this work would be helpful in improving the image property of the medium-energy radiography and could be supplied as a valuable reference when designing and fabricating an anti-scatter grid for high-energy flash radiography.
- X-ray optics /
- medium-energy radiography /
- anti-scatter grid /
- Monte Carlo simulation

HTML全文

图 1 散射光入射单个小孔示意图

Figure 1. Schematic of a scattered ray transferring through a single grid hole

下载: 全尺寸图片幻灯片

图 2 透射立体角与网栅厚度以及散射光能量的关系

Figure 2. Transmission solid angle profiles for different thicknesses of grid and energies of scattered photon

下载: 全尺寸图片幻灯片

图 3 X光辐射实验示意图

Figure 3. Schematic of X-ray radiographic experiment

下载: 全尺寸图片幻灯片

图 4 重采样前后的网栅照相图像

Figure 4. Images before and after resampling

下载: 全尺寸图片幻灯片

图 5 实验所得网栅透过率

Figure 5. Transmittance of grid derived by experiment

下载: 全尺寸图片幻灯片

图 6 有无网栅时的样品图像

Figure 6. Sample images with and without grid

下载: 全尺寸图片幻灯片

图 7 过样品中心的图像截面灰度比较

Figure 7. Comparison of the gray profile for sample

下载: 全尺寸图片幻灯片

图 8 MCNP模拟结果

Figure 8. Simulation results of MCNP

下载: 全尺寸图片幻灯片

表 1 有无网栅时图像对比度比较

Table 1. Contrast comparison between the cases with and without grid

thickness of PMMA plate/mm	without grid, R_s		with grid, R_g
thickness of PMMA plate/mm	MC simulation	experiment	MC simulation	experiment
40	1.366	1.679	2.392	2.465
80	1.249	1.470	2.312	2.326
—*		1.044		1.265
*2 mm grid case in our former work.

下载: 导出CSV

参考文献(31)

[1]	Yoder T D. Invisible culture: The use of soft X-ray radiography in perishable research[J]. Journal of Archaeological Method & Theory, 2013, 20(1): 1-17.
[2]	Takahashi H, Harada K, Nakazawa M, et al. Development of a new X-ray radiography system with 16 amorphous silicon linear sensors[J]. IEEE Trans Nuclear Science, 1993, 40(6): 2026-2029. doi: 10.1109/23.273448
[3]	Barry K, Kumar S, Linke R, et al. A clinical audit of anatomical side marker use in a paediatric medical imaging department[J]. Journal of Medical Radiation Science, 2016, 63(3): 148-154. doi: 10.1002/jmrs.176
[4]	Connolly C. X-ray systems for security and industrial inspection[J]. Sensor Review 2008, 28(3): 194-198. doi: 10.1108/02602280810882535
[5]	Catalin G A, Dumitru T C. Industrial image processing using fuzzy-logic[J]. Procedia Engineering, 2015, 100: 492-498. doi: 10.1016/j.proeng.2015.01.404
[6]	Watson S A, Kauppila T, Morrison L, et al. Pulsed high energy radiographic machine emitting X-rays (PHERMEX) flash radiographic camera[C]//Proc of SPIE. 1997, 2869: 920-928.
[7]	Watson S A. Contrast in radiography: The princess and the pea[R]. LA-UR-05-0950, 2005.
[8]	刘进, 刘军, 李必勇, 等. 基于平板模型的X射线散射特性研究[J]. 强激光与粒子束, 2006, 18(1): 173-176. http://www.hplpb.com.cn/article/id/2384 Liu Jin, Liu Jun, Li Biyong, et al. Scatter law of flat model. High Power Laser and Particle Beams, 2006, 18(1): 173-176 http://www.hplpb.com.cn/article/id/2384
[9]	刘军, 黄娇凤, 刘进, 等. 闪光照相散射模拟结果实验检验[J]. 强激光与粒子束, 2012, 24(12): 2991-2995. doi: 10.3788/HPLPB20122412.2991 Liu Jun, Huang Jiaofeng, Liu Jin, et al. Experimental verification of scattering simulation in flash radiography. High Power Laser and Particle Beams, 2012, 24(12): 2991-2995 doi: 10.3788/HPLPB20122412.2991
[10]	施将军, 李必勇, 宗嵩, 等. 高能闪光照相中钨球散射规律研究[J]. 强激光与粒子束, 2004, 16(4): 526-530. http://www.hplpb.com.cn/article/id/889 Shi Jiangjun, Li Biyong, Zong Song, et al. Research on scatter law of tungsten sphere in high energy flash X-ray radiography. High Power Laser and Particle Beams, 2004, 16(4): 526-530 http://www.hplpb.com.cn/article/id/889
[11]	Arridge S R. Optical tomography in medical imaging[J]. Inverse Problems, 1999, 15(2): R41-R93. doi: 10.1088/0266-5611/15/2/022
[12]	Jun T, Hiroshi M, Yasuyuki O. Light diffusion model for determination of optical properties of rectangular parallelepiped highly scattering media[J]. Applied Optics, 2007, 46(14): 2649-2655. doi: 10.1364/AO.46.002649
[13]	Danyk A Y, Radchenko S P, Sudakov O O. Optimization of grid-less scattering compensation in X-ray imaging: Simulation study[C]//IEEE 37th International Conference on Electronics and Nanotechnology. 2017.
[14]	Rührnschopf E P, Klingenbeck K. A general framework and review of scatter correction methods in cone-beam CT. Part 1. Scatter compensation approaches[J]. Medical Physics, 2011, 38(7): 4296-4311. doi: 10.1118/1.3599033
[15]	Rührnschopf E P, Klingenbeck K. A general framework and review of scatter correction methods in cone-beam CT. Part 2. Scatter estimation approaches[J]. Medical Physics, 2011, 38(9): 5186-5199. doi: 10.1118/1.3589140
[16]	Andrew S P, Robert G G, Jesse L C, et al. How much does lead shielding during fluoroscopy reduce radiation dose to out-of-field body parts[J]. Journal of Medical Imaging and Radiation Sciences, 2016, 47(2): 171-177.
[17]	Bucky G. An improved device for obtaining Rontgen ray exposures: US Patent 1164987[P]. 1915.
[18]	Igor S, Damjana K, Martin T, et al. The effect of anti-scatter grid on radiation dose in chest radiography in children[J]. Paediatrics Today, 2016, 12(1): 75-80.
[19]	Porubszky T. Anti-scatter grids, applied in diagnostic radiology[C]//European Medical Physics and Engineering Conference. 2012.
[20]	Fritz S, Jones K A. Guidelines for anti-scatter grid use in pediatric digital radiography[J]. Pediatr Radiol, 2014, 44(3): 313-321.
[21]	Bottari S, Ciocci M A, Fortunato M, et al. Study of a new scatter rejection technique in digital radiography[J]. Nuclear Instruments and Methods in Physics Research A, 2001, 461(1/3): 410-412.
[22]	Watson S A, Appleby M, Klinger J, et al. Design, fabrication and testing of a large anti-scatter grid for megavolt γ-ray imaging[C]//IEEE Nuclear Science Symposium Conference Record. 2005, 2: 717-721.
[23]	Konstantin P, Gaikovich P K, Gaikovich Y S, et al. Dual regularization in non-linear inverse scattering problems[J]. Inverse Problems in Science and Engineering, 2016, 24(7): 1215-1239.
[24]	王绍钢, 王苏程, 张磊. 高分辨透射X射线三维成像在材料科学中的应用[J]. 金属学报, 2013, 49(8): 897-910. https://www.cnki.com.cn/Article/CJFDTOTAL-JSXB201308002.htm Wang Shaogang, Wang Sucheng, Zhang Lei. Application of high resolution transmission X-ray tomography in material science. Acta Metallurgica Sinica, 2013, 49(8): 897-910 https://www.cnki.com.cn/Article/CJFDTOTAL-JSXB201308002.htm
[25]	吉幸, 罗贤, 杨延清, 等. 连续纤维增强金属基复合材料无损检测研究进展[J]. 稀有金属材料与工程, 2013, 42(s2): 401-405. https://www.cnki.com.cn/Article/CJFDTOTAL-COSE2013S2094.htm Ji Xing, Luo Xian, Yang Yanqing, et al. Research progress of nondestructive testing for continuous fiber-reinforced metal-matrix composites. Rare Metal Materials and Engineering, 2013, 42(s2): 401-405 https://www.cnki.com.cn/Article/CJFDTOTAL-COSE2013S2094.htm
[26]	师绍猛, 陈荣昌, 薛艳玲, 等. 强吸收介质内部低Z材料结构的X射线显微成像研究[J]. 物理学报, 2008, 57(10): 6319-6328. https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200810043.htm Shi Shaomeng, Chen Rongchang, Xue Yanling, et al. X-ray microscopic imaging of low Z material wrapped by strongly absorbing medium. Acta Physica Sinica, 2008, 57(10): 6319-6328 https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200810043.htm
[27]	刘丽想, 杜国浩, 胡雯, 等. 利用定量相衬成像消除X射线同轴轮廓成像中散射的影响[J]. 物理学报, 2006, 55(12): 6387-6394. https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200612031.htm Liu Lixiang, Du Guohao, Hu Wen, et al. Application of quantitative imaging to elimination of scattering effect on X-ray in-line outline imaging. Acta Physica Sinica, 2006, 55(12): 6387-6394 https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200612031.htm
[28]	陈永涛, 唐小军, 李庆忠. Fe基α相合金的冲击相变及其对层裂行为的影响研究[J]. 物理学报, 2011, 60: 046401. https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB201104082.htm Chen Yongtao, Tang Xiaojun, Li Qingzhong. Phase transition and inf1uence of phase transition on spall in a phase Fe-based alloy. Acta Physica Sinica, 2011, 60: 046401. https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB201104082.htm
[29]	陈永涛, 任国武, 汤铁钢, 等. 爆轰加载下金属样品的熔化破碎现象诊断[J]. 物理学报, 2013, 62: 116202. https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB201311055.htm Chen Yongtao, Ren Guowu, Tang Tiegang, et al. Experimental diagnostic of melting fragments under explosive loading. Acta Physica Sinica, 2013, 62: 116202 https://www.cnki.com.cn/Article/CJFDTOTAL-WLXB201311055.htm
[30]	刘文杰, 马庆鹏, 范诚, 等. 一种中能闪光X射照线光相学降散射网栅的设计及实验验证[J]. 光学学报, 2015, 35: 0934001. Liu Wenjie, Ma Qingpeng, Fan Cheng, et al. Design and performance testing of an anti-scattering grid for medium-energy flash radiography. Acta Optica Sinica, 2015, 35: 0934001
[31]	Briesmeister J F. MCNP—A general Monte Carlo N-particle transport code: version 4B[R]. LA-12625-M, 1997.
