Design of defected ground structure microstrip low-pass filters
-
摘要: 提出了一种具有宽带带外抑制的小型化微带低通滤波器。该滤波器由缺陷地结构和两阶阶跃阻抗单元结构构成。利用ANSYS HFSS建立三维全波电磁模型并仿真优化，仿真结果表明：该低通滤波器的截止频率为1.4 GHz，通带宽度为0~1.4 GHz，通带内的插入损耗小于0.5 dB，带外抑制频率范围为2.1~11 GHz，在阻带范围内的带外抑制能力接近20 dB。为验证仿真和测试结果，加工并测试了经全波电磁优化后的缺陷地结构微带低通滤波器。测试结果和仿真结果吻合得较好，证明了所提出的缺陷地结构在实现滤波器小型化和宽阻抗带宽上有着重要的作用，能够使该滤波器具有较好的低通滤波特性。Abstract: A novel compact microstrip low-pass filter with wideband suppression is proposed in this paper. The filter is composed of defect ground structure (DGS) and stepped impedance structure unit. The model was built and optimized by ANSYS HFSS. The simulation results show that the cut-off frequency of the low-pass filter is 1.4 GHz, the passband width is 0-1.4 GHz, the insertion loss in the passband is less than 0.5 dB, the out-of-band rejection frequency width is from 2.1 GHz to 11 GHz, and the out-of-band rejection in the stopband range is about 20 dB. In order to verify the test results and simulation results, an optimized defect-structured microstrip low-pass filter was processed and tested. The practical measurement are in good agreement with the simulation results. It is proved that the defect ground structure plays an important role in realizing the miniaturization of the filter and the wide impedance bandwidth. Moreover, the defect ground structure provides better low-pass filtering characteristics to the filter.
-
图 1 缺陷地基本结构单元
Figure 1. Basic unit cell of the defected ground structure (DGS) loaded microstrip
图 3 初始阶跃阻抗低通滤波器的顶部和底部的加工实物图
Figure 3. Top and bottom views of the fabricated DGS low-pass filter
图 4 初始阶跃阻抗低通滤波器的仿真与实测结果图
Figure 4. Simulation and measured results of the initially fabricated DGS low-pass filter
图 7 优化的DGS低通滤波器等效电路仿真和HFSS仿真结果图
Figure 7. Simulation of equivalent circuit and HFSS of DGS low-pass filter
图 8 改进的缺陷地结构低通滤波器顶部和底部的实物图
Figure 8. Top and bottom views of the modified DGS low-pass fiter
图 9 改进的DGS低通滤波器HFSS仿真与实测结果图
Figure 9. Simulation and measured results of modified DGS low-pass filter
表 1 缺陷地结构体统滤波器的等效电路元件参数表
Table 1. Equivalent circuit parameters of the DGS low-pass filter
L1/nH L2/nH L3/nH C1/pF C2/pF C3/pF C4/pF 2 10 0.6 0.1 2 4 0.2
下载: 导出CSV
-
[1] Young L. Microwave filters[J]. IEEE Trans Microwave Theory and Techniques, 1965, 13(5): 489-508. doi: 10.1109/TMTT.1965.1126046 [2] Kim T, Seo C. A novel photonic bandgap structure for low-pass filter of wide stopband[J]. IEEE Microwave and Guided Wave Letters, 2000, 10(1): 13-15. doi: 10.1109/75.842072 [3] Yang Y, Zhu X, Karmakar N C. A novel microstrip lowpass filter using compact microstrip resonant cells and uniquely shaped defected ground structures[J]. Microwave and Optical Technology Letters, 2012, 54(11): 2462-2464. doi: 10.1002/mop.27126 [4] Zhang R, Mansour R R. Novel digital and analogue tunable lowpass filters[J]. IET Microwaves, Antennas & Propagation, 2007, 1(3): 549-555. [5] Kumar L, Parihar M S. A compact reconfigurable low-pass filter with wide-stopband rejection bandwidth[J]. IEEE Microwave and Wireless Components Letters, 2018, 28(5): 401-403. doi: 10.1109/LMWC.2018.2823001 [6] Kumar L, Parihar M S. A wide stopband low-pass filter with high roll-off using stepped impedance resonators[J]. IEEE Microwave and Wireless Components Letters, 2018, 28(5): 404-406. doi: 10.1109/LMWC.2018.2816520 [7] Chen F C, Li R S, Chu Q X. Ultra-wide stopband low-pass filter using multiple transmission zeros[J]. IEEE Access, 2017, 5: 6437-6443. [8] Cao S, Han Y, Chen H, et al. An ultra-wide stop-band LPF using asymmetric pi-shaped Koch fractal DGS[J]. IEEE Access, 2017, 5: 27126-27131. doi: 10.1109/ACCESS.2017.2773577 [9] Ting S W, Tam K W, Martins R P. Miniaturized microstrip lowpass filter with wide stopband using double equilateral U-shaped defected ground structure[J]. IEEE Microwave and Wireless Components Letters, 2006, 16(5): 240-242. doi: 10.1109/LMWC.2006.873592 [10] Park J I, Kim C S, Kim J, et al. Modeling of a photonic bandgap and its application for the low-pass filter design[C]//1999 Asia Pacific Microwave Conference. 1999, 2: 331-334. [11] Ahn D, Park J S, Kim C S, et al. A design of the low-pass filter using the novel microstrip defected ground structure[J]. IEEE Trans Microwave Theory and Techniques, 2001, 49(1): 86-93. doi: 10.1109/22.899965 -
