Thorpe尺度估算库尔勒、茂名、拉萨大气光学湍流廓线

胡晓丹; 苏昶东; 罗涛; 青春; 孙刚; 刘庆; 李学彬; 朱文越; 吴晓庆

doi:10.11884/HPLPB201931.190074

Thorpe尺度估算库尔勒、茂名、拉萨大气光学湍流廓线

doi: 10.11884/HPLPB201931.190074

胡晓丹^{1, 2,},
苏昶东^{1, 2},
罗涛¹,
青春¹,
孙刚¹,
刘庆¹,
李学彬¹,
朱文越¹,
吴晓庆^1, ,

1.
中国科学院安徽光学精密机械研究所中国科学院大气光学重点实验室, 合肥 230031
2.
中国科学技术大学研究生院科学岛分院, 合肥 230031

基金项目:

国家自然科学基金项目 41576185

国家自然科学基金项目 91752103

中国科学院战略性先导科技专项(A类) 基金项目 XDA17010104

详细信息

作者简介:
胡晓丹(1994—), 女, 硕士研究生, 主要从事大气光学特性及其测量技术方面的研究, huxd2016@mail.ustc.edu.cn

通讯作者:
吴晓庆(1963—), 男, 博士, 研究员, 主要从事大气边界层、大气湍流测量与模式、天文选址等方面的研究, xqwu@aiofm.ac.cn

中图分类号: P427.1
计量
- 文章访问数: 1393
- HTML全文浏览量: 295
- PDF下载量: 68
- 被引次数: 0
出版历程
- 收稿日期: 2019-03-16
- 修回日期: 2019-04-24
- 刊出日期: 2019-08-15

Estimating the profiles of atmospheric turbulence above Korla, Maoming, Lhasa by Thorpe scale

Hu Xiaodan^{1, 2
,},
Su Changdong^{1, 2},
Luo Tao¹,
Qing Chun¹,
Sun Gang¹,
Liu Qing¹,
Li Xuebin¹,
Zhu Wenyue¹,
Wu Xiaoqing^{1
, ,}

1.
Key Laboratory of Atmospheric Optics, Anhui Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Hefei 230031, China
2.
Science Island Branch of Graduate School, University of Science and Technology of China, Hefei 230031, China

摘要

摘要: 在新疆库尔勒、广东茂名海边、西藏拉萨三个地区释放的探空气球, 实现了温度、气压、风速等常规气象参数以及大气折射率结构常数的廓线测量。基于Tatarski湍流参数化方案以及以上地区探空数据, 利用Thorpe尺度估算了新疆库尔勒、广东茂名海边、西藏拉萨三个地区的高空大气光学湍流廓线, 并将这三个地区实测的廓线与其对应的估算结果做了对比, 结果表明: 估算值与实测值在量级和变化趋势上表现出较好的一致性, 相关性分别为69%, 60%, 68%;Thorpe尺度相较于其他估算湍流廓线的参数化方法输入参数少、更简便。
- 大气光学 /
- 湍流廓线 /
- Thorpe尺度 /
- 湍流参数化
Abstract: The sounding balloons released from Korla, Maoming, Guangdong and Lhasa, Tibet, have been used to measure the profiles of temperature, air pressure and wind velocity and the refractive index structure constants of the atmosphere.Based on the optical turbulence parameterization of Tatarski theory and the above-mentioned areas sounding data, the atmospheric optical turbulence profiles in three regions, Korla, Xinjiang the coast of Maoming, Guangdong and Lhasa, Tibet, are estimated by using Thorpe scale.Estimated results are compared with measured profiles in these three regions.The estimated values and the measured values are in good agreement with each other in the order of magnitude and the trend of change, and the correlation are69%, 60%, 68%, respectively.In addition, compared with other parameterized methods for estimating turbulence profiles, the Thorpe scale is simple and has less input parameters.
- atmospheric optics /
- turbulence profile /
- Thorpe scale /
- turbulence parameterization

HTML全文

图 1 Thorpe尺度估算步骤

Figure 1. Thorpe scale estimation steps

下载: 全尺寸图片幻灯片

图 2 库尔勒地区实测与估算C_n²廓线比较.(a)—(f)分别表示6个探空数据

Figure 2. Comparison of observed and estimated C_n² profiles in Korla. The panels (a)—(f) represent six sounding data respectively

下载: 全尺寸图片幻灯片

图 3 名地区实测与估算C_n²廓线比较.(a)—(f)分别表示6个探空数据

Figure 3. Comparison of observed and estimated C_n² profiles in Maoming. The panels (a)—(f) represent six sounding data respectively

下载: 全尺寸图片幻灯片

图 4 拉萨地区实测与估算C_n²廓线比较.(a)—(f)分别表示6个探空数据

Figure 4. Comparison of observed and estimated C_n² profiles in Lhasa. The panels (a)—(f) represent six sounding data respectively

下载: 全尺寸图片幻灯片

表 1 三地实验记录

Table 1. Experimental information of three sites

site	latitude andlongitude	height abovesea level/m	observationtime	effective totalnumber	detectionparameters
Korla	41.68°N 86.06°E	950	2015.11	21	temperature/pressure wind direction/wind speed C_n²
Maoming	21.40°N 110.53°E	30	2016.12—2017.01	21	temperature/pressure wind direction/wind speed humidity/C_n²
Lhasa	29.97°N 91.11°E	3650	2018.08	9	temperature/pressure wind direction/wind speed humidity/C_n²

下载: 导出CSV

表 2 三地估测值与实测值相关性及c₁值统计

Table 2. Statistics of the correlation between the estimated value and c₁ value in three areas

site	correlation/%	c₁
Korla	69	0.12
Maoming	60	0.14
Lhasa	68	0.75

下载: 导出CSV

参考文献(14)

[1]	袁仁民, 曾宗泳, 肖黎明, 等. 不同方法测量折射率结构常数的比较[J]. 光学学报, 2000, 20(6): 755-761. doi: 10.3321/j.issn:0253-2239.2000.06.007 Yuan Renmin, Zeng Zongyong, Xiao Liming, et al. Comparison of some methods of measuring refractive index structure parameter. Acta Optica Sinica, 2000, 20(6): 755-761 doi: 10.3321/j.issn:0253-2239.2000.06.007
[2]	吴晓庆. 大气光学湍流、模式与测量技术[J]. 安徽师范大学学报, 2006, 29(2): 103-107. doi: 10.3969/j.issn.1001-2443.2006.02.001 Wu Xiaoqing. Atmospheric optical turbulence, model and measurement techniques. Journal of Anhui Normal University, 2006, 29(2): 103-107 doi: 10.3969/j.issn.1001-2443.2006.02.001
[3]	许利明, 吴晓庆, 王英俭. 用常规气象参数估算光学湍流廓线方法的比较[J]. 强激光与粒子束, 2008, 20(1): 53-57. http://www.hplpb.com.cn/article/id/3478 Xu Liming, Wu Xiaoqing, Wang Yingjian. Methods comparision of estimating optical turbulence profile using conventional meteorology parameters. High Power Laser and Particle Beams, 2008, 20(1): 53-57 http://www.hplpb.com.cn/article/id/3478
[4]	Tatarski V I. Wave propagation in a turbulent medium[M]. McGraw, 1961.
[5]	Dewan E M, Good R E, Beland R R, et al. A model for C_n² (optical turbulence) profiles using radiosonde data[R]. PL-TR-93-2043.
[6]	Coulman C E, Vernin J. Significance of anisotropy and outer scale of turbulence for optical and radio seeing[J]. Applied Optics, 1991, 30(1): 118-126. doi: 10.1364/AO.30.000118
[7]	Thorpe S A. Turbulence and mixing in a Scottish loch[J]. Philosophical Transactions of the Royal Society A: Mathematical, Physical and Engineering Sciences, 1977, 286(1334): 125-181.
[8]	Luce H, Fukao S, Dalaudier F, et al. Strong mixing events observed near the tropopause with the MU radar and high-resolution balloon techniques[J]. Journal of the Atmospheric Sciences, 2002, 59(20): 2885-2896. doi: 10.1175/1520-0469(2002)059<2885:SMEONT>2.0.CO;2
[9]	Gavrilov N M, Luce H. Turbulence parameter estimations from high-resolution balloon temperature measurements of the MUTSI-2000 campaign[J]. Annales Geophysicae, 2005, 23(7): 2401-2413. doi: 10.5194/angeo-23-2401-2005
[10]	Basu S. A simple approach for estimating the refractive index structure parameter (C_n²) profile in the atmosphere[J]. Optics Letters, 2015, 40(17): 4130-4133. doi: 10.1364/OL.40.004130
[11]	Sorbjan Z, Balsley B B. Microstructure of turbulence in the stably stratified boundary layer[J]. Boundary-Layer Meteorology, 2008, 129(2): 191-210. doi: 10.1007/s10546-008-9310-1
[12]	Mater B D, Schaad S M, Venayagamoorthy S K. Relevance of the Thorpe length scale in stably stratified turbulence[J]. Physics of Fluids, 2013, 25(7): 076604-1-076604-13. doi: 10.1063/1.4813809
[13]	Dillon T M. Vertical overturns: A comparison of Thorpe and Ozmidov length scales[J]. Journal of Geophysical Research Oceans, 1982, 87(C12): 9601-9613. doi: 10.1029/JC087iC12p09601
[14]	史军强, 陈学恩. 基于舟山外海连续测站的湍混合研究[J]. 中国海洋大学学报(自然科学版), 2015, 45(3): 25-32. doi: 10.16441/j.cnki.hdxb.20130370 Shi Junqiang, Chen Xueen. Study on turbulent mixing based on the in-situ continuous observations station in the Zhoushan Sea. Periodical of Ocean University of China, 2015, 45(3): 25-32 doi: 10.16441/j.cnki.hdxb.20130370
