325 MHz中β超导Spoke腔的腔型对比和选择

张蒙 , 贺斐思 , 潘卫民

文章导航 > 强激光与粒子束 > 2019 > 31(11) : 31115101

引用本文:

Citation:

325 MHz中β超导Spoke腔的腔型对比和选择

1. 中国科学院大学, 北京 100049;
2. 中国科学院粒子加速物理与技术重点实验室, 北京 100049

作者简介: 张蒙(1993-),男,硕士,主要从事加速器超导高频Spoke腔的计算仿真方面研究;zhangmeng@ihep.ac.cn。.

中图分类号: TN815

Design and selection of 325 MHz medium β Spoke cavity

1. University of Chinese Academy of Sciences, Beijing 100049, China;
2. Key Laboratory of Particle Acceleration Physics & Technology, Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
CLC number: TN815

摘要: 中国科学院高能物理研究所一直在研究频率为325 MHz、中低β Spoke超导加速腔，以应用在加速器驱动的次临界系统（ADS）的强流质子直线加速器中。通过对超导腔设计方法和设计原则的研究，使用CST仿真软件设计了单Spoke腔、双Spoke腔、三bar Spoke腔三种Spoke腔型。其中三bar Spoke腔和双Spoke腔一样，都有着三个加速间隙，但是Spoke柱的结构不同。在腔型设计中，对三种Spoke腔的模型均作了参数化处理。然后通过CST的参数化扫描来优化腔体形状以使得峰值电场与加速梯度的比值最小，同时使峰值磁场与加速梯度的比值处于较低范围。本文对三种腔型进行了高频结构优化和参数分析，选用了双Spoke腔型作为设计方案，并对电磁场等进行了优化设计。
- 质子加速器 /
- 单Spoke腔 /
- 双Spoke腔 /
- 三bar Spoke腔 /
- 中β
Abstract: A 325 MHz Spoke cavity at medium and low β is developed in institute of High Energy Physics (IHEP) for the CiADS linac. Through the study on the principle of designing a superconducting cavity, three kinds of Spoke cavities including single Spoke cavity, double Spoke cavity and 3-bar Spoke cavity, were designed by the CST MWS. Although both the 3-bar Spoke and the double Spoke have a 3-gap structure, their Spoke bars are different. In the process of cavity design, parametric modeling was used to construct the cavity shape. Then the cavity shape was optimized by the parametric sweep in the CST MWS to minimize ratio of peak electric field to accelerating gradient (E_P/E_acc) while keeping ratio of peak magnetic field to accelerating gradient (B_P/E_acc) at a reasonably low range. Through the comparison of RF performance parameters, a double Spoke structure was selected as the design, and further optimization for electromagnetic field of double Spoke cavity is carried out.
- proton accelerator /
- single Spoke cavity /
- double Spoke cavity /
- 3-bar Spoke cavity /
- medium β
