基于窄脉冲传输的脉冲展宽IGBT驱动电路

石经纬; 赵娟; 冯荣欣

doi:10.11884/HPLPB201931.190206

基于窄脉冲传输的脉冲展宽IGBT驱动电路

doi: 10.11884/HPLPB201931.190206

1.
中国商用飞机有限责任公司北京民用飞机技术研究中心，北京 102211
2.
北京荣广盛工程管理有限公司，北京 100089

详细信息

作者简介:
石经纬(1984－), 男，博士，工程师，从事固态高压脉冲电源和等离子体表面改性技术研究; jingweishi@163.com

中图分类号: TM46;TN710
计量
- 文章访问数: 1325
- HTML全文浏览量: 200
- PDF下载量: 76
- 被引次数: 0
出版历程
- 收稿日期: 2019-06-10
- 修回日期: 2019-07-20
- 刊出日期: 2019-11-15

Driving circuit for IGBTs with long pulse duration based on narrow pulses broadening

1.
Beijing Aeronautical Science & Technology Research Institute of Commercial Aircraft Corporation of China, Ltd, Beijing 102211, China
2.
Beijing ROCOSN Engineering Management Co, Ltd, Beijing 100089, China

摘要

摘要: 设计了一种采用高压隔离脉冲变压器传输窄脉冲，然后应用脉冲展宽电路实现宽脉冲驱动信号输出的无源IGBT驱动电路。采用正电压turn-on窄脉冲和负电压turn-off窄脉冲组合传输的方式以减小高压隔离脉冲变压器的体积和重量，脉冲展宽电路使IGBT在turn-on脉冲上升沿导通，在turn-off脉冲上升沿关断，且其具备储能功能，无需高压隔离辅助直流电源为其供电。脉冲信号发生电路和过流保护电路耦合设计，使IGBT在正常关断和过流保护关断情况下，其栅极都处于反压偏置状态，以提高IGBT关断的快速性和可靠性。将驱动电路用于级联Marx高压电路中IGBT开关的驱动，turn-on脉冲和turn-off脉冲的脉宽均选择为2 μs，结果表明，Marx电路在输出脉冲电压峰值为20 kV时工作稳定，且脉宽在3.5~50 μs之间连续可调，等离子体负载下的输出电压和电流波形显示，打火情况发生时，过流保护电路工作稳定可靠。该驱动电路可有效实现宽脉冲驱动信号的产生，具有较强的可靠性和实用性。
- 高压隔离脉冲变压器 /
- 窄脉冲 /
- 脉冲展宽 /
- IGBT /
- 驱动电路 /
- 过流保护 /
- Marx电路
Abstract: This paper proposes a driving circuit for IGBTs with long duration gating signals output, by which only narrow pulses are transferred by the high-voltage isolation pulse transformer and no high-voltage isolation DC power supplies are utilized. Narrow positive pulse "turn-on" and negative pulse "turn-off" are both transferred by the pulse transformer which is smaller and lighter, comparing with that transferring long duration gating signals. The pulse width broadening circuit turns the IGBTs on at the rising edge of "turn-on" pulse and turns the IGBTs off at the rising edge of "turn-off" pulse, and it also stores energy from "turn-on" pulse, without high-voltage isolation DC power supplies. Narrow pulses generator and over-current protection circuit are interactively designed to produce negative voltage pulse on the gate of IGBTs, which reduces the turn off transition period and enhances the turn off reliability, whether the IGBTs are normally turned off or closed due to over-current protection. The proposed driving circuit is applied to the cascaded high-voltage Marx generator, and the pulse widths of "turn-on" and "turn-off" pulses are both 2 μs. Experimental results show that the Marx generator functions well with maximum voltage output of 20 kV and pulse width at 3.5~50 μs. When arcing generates at plasma load, the over-current protection circuit reacts quickly to turn off the IGBTs with high reliability. The performance of the driving circuit proves its capability of producing long duration gating signals for IGBTs with high reliability and practical validity.
- high-voltage isolation pulse transformer /
- narrow pulse /
- pulse width broadening /
- IGBT /
- driving circuit /
- over-current protection /
- Marx generator

HTML全文

图 1 驱动电路结构示意图

Figure 1. Schematic diagram of proposed driving circuit for IGBT

下载: 全尺寸图片幻灯片

图 2 驱动电路脉冲波形示意图

Figure 2. Pulse waveforms produced by the driving circuit

下载: 全尺寸图片幻灯片

图 3 脉冲turn-on和turn-off产生电路图

Figure 3. Circuit for turn-on and turn-off pulses generation

下载: 全尺寸图片幻灯片

图 4 高压隔离脉冲变压器

Figure 4. Pulse transformer with high-voltage isolation

下载: 全尺寸图片幻灯片

图 5 脉冲展宽电路图

Figure 5. Pulse width broadening circuit

下载: 全尺寸图片幻灯片

图 6 脉冲展宽电路工作状态

Figure 6. Operation principles of pulse width broadening circuit

下载: 全尺寸图片幻灯片

图 7 脉冲展宽电路波形图

Figure 7. Experimental voltage waveforms of the pulse width broadening circuit

下载: 全尺寸图片幻灯片

图 8 不同脉冲宽度时的U_G电压波形

Figure 8. Experimental waveforms of grid voltage U_G with various pulse widths

下载: 全尺寸图片幻灯片

图 9 不同脉冲宽度时的高压脉冲波形

Figure 9. Experimental waveforms of output voltage U_o with various pulse widths

下载: 全尺寸图片幻灯片

图 10 等离子体负载下的电压电流波形

Figure 10. Waveforms of U_o and I_o at plasma load

下载: 全尺寸图片幻灯片

参考文献(19)

[1]	Zhu J D, Liang J Q, Lu Y, et al. A new IGBT control and drive circuit for high-power full-bridge inverter for electrostatic precipitators[J]. Journal of Electrostatics, 2013(71): 235-239.
[2]	丁明军, 李玺钦, 冯宗明, 等. 200 kV全固态Marx结构方波脉冲电源设计[J]. 强激光与粒子束, 2017, 29: 025009. doi: 10.11884/HPLPB201729.160453 Ding Mingjun, Li Xiqin, Feng Zongming, et al. Design of 200 kV solid-state square-wave pulse power supply based on Marx topology. High Power Laser and Particle Beams, 2017, 29: 025009). doi: 10.11884/HPLPB201729.160453
[3]	Steenkamp C J T, Bradley M P. Active charge/discharge IGBT modulator for Marx generator and plasma applications[J]. IEEE Transactions on Plasma Science, 2007, 35(2): 473-478. doi: 10.1109/TPS.2007.892739
[4]	余琳, 黄康, 王海军, 等. 绝缘栅双极晶体管串联关键技术[J]. 强激光与粒子束, 2013, 25(5): 1315-1319. doi: 10.3788/HPLPB20132505.1315 Yu Lin, Huang Kang, Wang Haijun, et al. Key technologies on series connection of insulated gate bipolar transistors. High Power Laser and Particle Beams, 2013, 25(5): 1315-1319 doi: 10.3788/HPLPB20132505.1315
[5]	朱晓光, 张政权, 刘庆想, 等. 脉冲功率应用的IGBT快速驱动电路[J], 强激光与粒子束, 2018, 30: 015001. doi: 10.11884/HPLPB201830.170330 Zhu Xiaoguang, Zhang Zhengquan, Liu Qingxiang, et al. High speed IGBT gate driving circuit applied to pulsed power system. High Power Laser and Particle Beams, 2018, 30: 015001 doi: 10.11884/HPLPB201830.170330
[6]	甄任贺. 负载波动下IGBT损坏分析及驱动电路优化设计[J]. 电力自动化设备, 2008, 28(4): 111-112. https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS200804028.htm Zhen Renhe. Analysis of IGBT damage under load fluctuation and optimal design of driving circuit. Electric Power Automation Equipment, 2008, 28(4): 111-112 https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS200804028.htm
[7]	师睿, 刘志刚, 张钢. 一种IGBT驱动电路及保护的优化和研制[J]. 机械与电子, 2008(9): 16-19. https://www.cnki.com.cn/Article/CJFDTOTAL-JXYD200809007.htm Shi Rui, Liu Zhigang, Zhang Gang. The research and improvement of driving circuit and protection circuit for IGBT. Machinery and Electronics, 2008(9): 16-19 https://www.cnki.com.cn/Article/CJFDTOTAL-JXYD200809007.htm
[8]	谢舜蒙, 杨光, 马伯乐, 等. 大功率IGBT驱动信号隔离技术研究[J]. 大功率变流技术, 2014(2): 18-22. https://www.cnki.com.cn/Article/CJFDTOTAL-BLJS201402005.htm Xie Shunmeng, Yang Guang, Ma Bole, et al. Research on signal isolation technologies of high-power IGBT driver. High Power Converter Technology, 2014(2): 18-22 https://www.cnki.com.cn/Article/CJFDTOTAL-BLJS201402005.htm
[9]	张佃青. 新型IGBT驱动脉冲变压器电路设计[J]. 变频器世界, 2013(3): 61-64. https://www.cnki.com.cn/Article/CJFDTOTAL-DQJS201703022.htm Zhang Dianqing. Circuit design for novel IGBT drive pulse transformer. The World of Inverters, 2013(3): 61-64 https://www.cnki.com.cn/Article/CJFDTOTAL-DQJS201703022.htm
[10]	苏斌, 吕征宇. 新型中高压隔离驱动电源的架构[J]. 电工技术学报, 2010, 25(2): 121-126. https://www.cnki.com.cn/Article/CJFDTOTAL-DGJS201002020.htm Su Bin, Lü Zhengyu. A novel drive power supply framework for medium-high voltage application. Transactions of China Electrotechnical Society, 2010, 25(2): 121-126 https://www.cnki.com.cn/Article/CJFDTOTAL-DGJS201002020.htm
[11]	王凌云, 王传伟, 李洪涛, 等. 500 kV固态Marx发生器IGBT多路驱动高压隔离供电电源的设计[J]. 高电压技术, 2012, 38(1): 236-240. https://www.cnki.com.cn/Article/CJFDTOTAL-GDYJ201201036.htm Wang Lingyun, Wang Chuanwei, Li Hongtao, et al. Design of 500 kV solid-state Marx generator IGBT drive voltage multi-channel insulated power supply. High Voltage Engineering, 2012, 38(1): 236-240 https://www.cnki.com.cn/Article/CJFDTOTAL-GDYJ201201036.htm
[12]	赵秋山, 冯冬青, 卢宜. 高压隔离的多路低压直流电源[J]. 电力自动化设备, 2010, 30(1): 136-139. https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS201001033.htm Zhao Qiushan, Feng Dongqing, Lu Yi. High-voltage isolated multi-channel low-voltage DC power supply. Electric Power Automation Equipment, 2010, 30(1): 136-139 https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS201001033.htm
[13]	丁祖军, 郑建勇, 梅军, 等. 基于EXB841的IGBT驱动电路设计及优化[J]. 电力自动化设备, 2004, 24(6): 37-40. https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS200406009.htm Ding Zujun, Zheng Jianyong, Mei Jun, et al. Design and optimization of EXB841-based IGBT driving circuitry. Electric Power Automation Equipment, 2004, 24(6): 37-40 https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS200406009.htm
[14]	Huang Y S, Zhu L, Xin Y G. Analysis and optimization design of M57959L module-based IGBT drive circuit[C]//IEEE Asia-Pacific Conference on Wearable Computing Systems. 2010: 239-242.
[15]	Abbate C, Busatto G, Fratelli L, et al. The robustness of series-connected high power IGBT modules[J]. Microelectronics Reliability, 2007, 47(9): 1746-1750.
[16]	李伟邦, 侯凯, 范镇淇, 等. 1700 V IGBT模块直接串联驱动设计[J]. 智能电网, 2013, 1(2): 31-36. https://www.cnki.com.cn/Article/CJFDTOTAL-ZNDW201302008.htm Li Weibang, Hou Kai, Fan Zhenqi, et al. Driver design for series connection of 1700 V IGBTs. Smart Grid, 2013, 1(2): 31-36 https://www.cnki.com.cn/Article/CJFDTOTAL-ZNDW201302008.htm
[17]	郑晟, 蔡卓剑, 汪槱生, 等. 适用于IGBT串联系统集成的驱动电路[J]. 浙江大学学报(工学版), 2013, 47(12): 2094-2100. https://www.cnki.com.cn/Article/CJFDTOTAL-ZDZC201312004.htm Zheng Sheng, Cai Zhuojian, Wang Yousheng, et al. Integrated driving circuit of IGBT serious connected system. Journal of Zhejiang University (Engineering Science), 2013, 47(12): 2094-2100 https://www.cnki.com.cn/Article/CJFDTOTAL-ZDZC201312004.htm
[18]	Ryoo H J, Kim J S, Rim G H, et al. Current loop gate driver circuit for pulsed power supply based on semiconductor switches[C]//IEEE 34th International Conference on Plasma Science. 2007: 1622-1626.
[19]	石经纬, 巩春志, 张可心, 等. 基于同步信号的多路延时IGBT驱动电路设计[J]. 电力自动化设备, 2012, 32(1): 123-126. https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS201201030.htm Shi Jingwei, Gong Chunzhi, Zhang Kexin, et al. A novel drive circuit based on synchronous signals with time delay for IGBTs. Electric Power Automation Equipment, 2012, 32(1): 123-126 https://www.cnki.com.cn/Article/CJFDTOTAL-DLZS201201030.htm
