Design of portable resonant voltage doubling capacitor charging power supply
-
摘要: 对输入电压为24 V，输出电压3 kV的便携式谐振倍压电容充电电源进行了设计与验证。针对高变压比的特点，电源采用串联谐振拓扑与倍压整流相结合的拓扑结构，避免了高频变压器副边匝数过多、分布参数过大可能造成的不利影响。对高频变压器、谐振电容、开关器件等核心元件进行了设计和调试。最后采用该电源进行电容充电实验，其测试结果验证了设计的正确性。Abstract: This paper presents the design and verification of a portable resonant voltage doubling capacitor charging power supply with an input voltage of 24 V and an output voltage of 3 kV. According to the characteristic of high voltage ratio, this power supply adopts a topology structure combining the series resonant topology and the voltage doubling rectifier, which avoids the adverse effects of excessive number of turns on the secondary side of the high frequency transformer and excessive distributed parameters. The core components such as high frequency transformer, resonant capacitor and switching device were designed and debugged. The power supply was used to conduct the capacitor charging experiment, and the test results have verified the correctness of the design.
-
图 2 简化的串联谐振充电电源原理图
Figure 2. Simplified principle diagram of series resonant charging power supply
图 5 便携式谐振倍压电容充电电源原理图
Figure 5. Principle diagram of portable resonant voltage doubling capacitor charging power supply
图 6 便携式谐振倍压电容充电电源
Figure 6. Portable resonant voltage doubling capacitor charging power supply
表 1 便携式谐振倍压电容充电电源电路参数
Table 1. Circuit parameters of portable resonant voltage doubling capacitor charging power supply
Vin/V fs/kHz D p n Lr/μH Cr/μF C1…C6/nF Cout/μF 24 100 0.25 3 50 0.05 9.4 150 6
下载: 导出CSV
-
[1] 雷发胜, 赵晓昕, 张广浩, 等. 重复经颅磁刺激器电容充电技术发展现状[J]. 电工电能新技术, 2016, 35(11):45-52. (Lei Fasheng, Zhao Xiaoxin, Zhang Guanghao, et al. Development status of repetitive transcranial magnetic stimulator capacitor charging technology[J]. Advanced Technology of Electrical Engineering and Energy, 2016, 35(11): 45-52 doi: 10.3969/j.issn.1003-3076.2016.11.008 [2] 王胜. 串联谐振式高压电容器充电电源研究[D]. 武汉: 华中科技大学, 2011.Wang Sheng. Research on series resonant high voltage capacitor charging power supply[D]. Wuhan: Huazhong University of Science and Technology, 2011 [3] Zhong Heqing, Xu Zhixin, Zou Xudong, et al. Current characteristic of high voltage capacitor charging power supply using a series resonant topology[C]//The 29th Annual Conference of the IEEE. 2003. [4] Lippincott A C, Nelms R M, Garbi M, et al. A series resonant converter with constant on-time control for capacitor charging applications[C]//Applied Power Electronics Conference and Exposition. 1990: 147-154. [5] 苏建仓, 王利民, 丁永忠, 等. 串联谐振充电电源分析及设计[J]. 强激光与粒子束, 2004, 16(12):1611-1614. (Su Jiancang, Wang Limin, Ding Yongzhong, et al. Analysis and design of series resonant charging power supply[J]. High Power Laser and Particle Beams, 2004, 16(12): 1611-1614 [6] 冯传均, 何泱, 戴文峰, 等. 串联谐振高压电容充电电源设计及分析[J]. 强激光与粒子束, 2019, 31:055002. (Feng Chuanjun, He Yang, Dai Wenfeng, et al. Design and analysis of series resonant high voltage capacitor charging power supply[J]. High Power Laser and Particle Beams, 2019, 31: 055002 [7] 朱鑫淼. 串联谐振充电电源设计[D]. 大连: 大连理工大学, 2014.Zhu Xinmiao. The design of series resonant charging power supply[D]. Dalian: Dalian University of Technology, 2014 [8] 银志军, 赵扬, 孙大维, 等. 倍压整流电路的仿真与分析[J]. 光电技术应用, 2006(5):71-75. (Yin Zhijun, Zhao Yang, Sun Dawei, et al. Simulation and analysis of voltage doubling rectifier circuit[J]. Electro-Optic Technology Application, 2006(5): 71-75 doi: 10.3969/j.issn.1673-1255.2006.05.019 [9] 闫良, 闫英敏, 杨凤彪. 倍压整流电路的分析和仿真[J]. 电子设计工程, 2017, 25(8):119-123. (Yan Liang, Yan Yingmin, Yang Fengqbiao. Analysis and simulation of voltage doubling rectifier circuit[J]. Electronic Design Engineering, 2017, 25(8): 119-123 [10] 乔恩明, 张双运. 开关电源工程设计快速入门[M]. 北京: 中国电力出版社, 2010.Qiao Enming, Zhang Shuangyun. Quick introduction to switching power supply engineering design[M]. Beijing: China Electric Power Press, 2010 [11] 赵志英. 高频变压器分布电容及其影响分析[C]//中国电工技术学会电力电子学会第十届学术年会. 2006.Zhao Zhiying. Stray capacitances and its effects in high frequency pulse transformers[C]//10th Annual Conference of the Institute of Power Electronics, China Electrotechnical Society. 2006 [12] 王冬冬. 串联谐振电容器充电电源的研制[D]. 武汉: 华中科技大学, 2008.Wang Dongdong. The research and development of series resonant capacitor charging power supply[D]. Wuhan: Huazhong University of Science and Technology, 2008 -
