雷电电磁脉冲对典型机载GPS模块的损伤效应研究

张万里 史云雷 何勇 沈杰 潘绪超 方中 陈鸿

张万里, 史云雷, 何勇, 等. 雷电电磁脉冲对典型机载GPS模块的损伤效应研究[J]. 强激光与粒子束, 2021, 33: 033001. doi: 10.11884/HPLPB202133.200264
引用本文: 张万里, 史云雷, 何勇, 等. 雷电电磁脉冲对典型机载GPS模块的损伤效应研究[J]. 强激光与粒子束, 2021, 33: 033001. doi: 10.11884/HPLPB202133.200264
Zhang Wanli, Shi Yunlei, He Yong, et al. Study on damage effects of lightning electromagnetic pulse on typical airborne GPS module[J]. High Power Laser and Particle Beams, 2021, 33: 033001. doi: 10.11884/HPLPB202133.200264
Citation: Zhang Wanli, Shi Yunlei, He Yong, et al. Study on damage effects of lightning electromagnetic pulse on typical airborne GPS module[J]. High Power Laser and Particle Beams, 2021, 33: 033001. doi: 10.11884/HPLPB202133.200264

雷电电磁脉冲对典型机载GPS模块的损伤效应研究

doi: 10.11884/HPLPB202133.200264
基金项目: 装备预研基金项目(61402090104);国家自然科学基金项目(11504173,11502118)
详细信息
    作者简介:

    张万里(1995—),男,硕士研究生,主要从事雷电间接效应研究;1372007310@qq.com

    通讯作者:

    何 勇(1964—),男,教授,博士生导师,主要从事弹药高效毁伤、智能弹药、电磁脉冲效应等方向的研究;yonghe1964@163.com

  • 中图分类号: TN972

Study on damage effects of lightning electromagnetic pulse on typical airborne GPS module

  • 摘要: 为研究雷电电磁脉冲对典型无人机机载GPS模块的损伤效应,通过仿真模拟和试验分析相结合的方法,获取了对GPS模块受雷电电磁脉冲暂态干扰与永久损伤过程的认识,并获得了相应端口的损伤阈值。基于对雷电流特性的分析结果,利用CST仿真模拟了雷击时,无人机内外产生的复杂电磁场环境和GPS模块线缆上耦合产生的感应电压。并对典型机载GPS模块的数据通讯端口进行了雷电脉冲注入试验。研究结果表明:随着雷电脉冲的不断增强,GPS输出波形受到削弱影响的程度不断加重,直至丧失位置信息传输能力并发生物理损伤。GPS数据输入端口的雷电脉冲损伤阈值为314.5 V,GPS数据输出端口的雷电脉冲损伤阈值为235.2 V。
  • 图  1  无人机3D模型

    Figure  1.  3D model of drone

    图  2  电流分量A的时域波形

    Figure  2.  Time domain waveform of current component A

    图  3  探针和线缆布局

    Figure  3.  Layout of probes and cable

    图  4  雷击电磁环境

    Figure  4.  Lightning electromagnetic environment

    图  5  线缆耦合感应电压

    Figure  5.  Transient voltage waveform on cable

    图  6  GPS模块

    Figure  6.  GPS module

    图  7  正常工作状态下GPS输出波形

    Figure  7.  GPS output waveform under normal working conditions

    图  8  注入试验布局

    Figure  8.  Layout of the injection experiment

    图  9  注入雷电脉冲波形

    Figure  9.  Waveform of the injected electric pulse

    图  10  不同U0条件下UPIP变化曲线

    Figure  10.  Variation trend of UP and IP under different condition of U0

    图  11  不同U0下端口2输出UHUL变化趋势

    Figure  11.  Variation trend of UH and UL under different condition of U0

    图  12  不断提高U0对GPS输出波形影响

    Figure  12.  Influence of increasing U 0 on GPS output waveform

    图  13  不同U0条件下UP变化曲线

    Figure  13.  Variation trend of UP under different condition of U0

    图  14  暂态干扰信号

    Figure  14.  Transient interference signal

    图  15  永久损伤信号

    Figure  15.  Permanent damage signal

    表  1  无人机材料参数

    Table  1.   Material parameters of the drone

    No.materialdensity/(kg·m−3permittivityconductivity/(S·m−1relative permeability/(H·m−1application
    1copper8500/5.8×1071motor
    2polyimide12002.4~4.5/1shell of battery, control module, stage
    3Al 70752800/351wing frame, main part
    4carbon fiber150053001panel
    下载: 导出CSV

    表  2  GPS模块端口信息

    Table  2.   GPS module port information

    No.nameI/Odescriptioncharacteristic
    1SDAOI2C bus master-slave datecompass clock pin
    2GNDGgroundground
    3TXOUART communication interfaceGPS date output pin
    4RXIUART communication interfaceGPS date input pin
    5VCCIDC supply3.6~5.5 V
    6SCLII2C bus master-slave datecompass clock pin
    下载: 导出CSV
  • [1] 李琛. 雷击环境下机载电子设备性能研究[D]. 西安: 西安电子科技大学, 2017.

    Li Chen. Research on the performance of airborne electronic device in the lightning environment[D]. Xi’an: Xidian University, 2017.
    [2] 刘贺楠, 郭俊, 伊同强, 等. 飞行器雷电直接效应与间接效应防护综述[J]. 宇航总体技术, 2019(4):56-62. (Liu Henan, Guo Jun, Yi Tongqiang, et al. Protection of direct and indirect effects of lightning on aircraft[J]. Aerospace System Engineering Technology, 2019(4): 56-62
    [3] 骆立峰. 雷电间接效应试验与标准解析[J]. 电子科学技术, 2014(1):97-101. (Luo Lifeng. Analysis of lightning indirect effects test and standard[J]. Electronic Science and Technology, 2014(1): 97-101
    [4] 仇善良, 段泽民, 司晓亮, 等. 直升机电子设备舱瞬态雷电感应磁场特性[J]. 高电压技术, 2017, 43(5):1409-1419. (Qiu Shanliang, Duan Zemin, Si Xiaoliang, et al. Transient lightning induced magnetic field characterisitics of helicopter electronic equipment cabin[J]. High Voltage Engineering, 2017, 43(5): 1409-1419
    [5] 陈奇平, 方金鹏, 王万富. 整机雷电间接效应防护试验的若干技术探讨[J]. 微波学报, 2012(s3):305-308. (Chen Qiping, Fang Jinpeng, Wang Wanfu. Discussion on aircraft lightning indirect effects test[J]. Journal of Microwaves, 2012(s3): 305-308
    [6] 沈杰, 潘绪超, 方中, 等. 强电磁脉冲对硅微惯性传感器的损伤效应研究[J]. 兵工学报, 2020, 41(6):1157-1164. (Shen Jie, Pan Xuchao, Fang Zhong, et al. Damage effect of strong electromagnetic pulse on micro-silicon inertial sensor[J]. Acta Armamentarii, 2020, 41(6): 1157-1164
    [7] 黄立洋, 陈晓宁, 郭飞, 等. 直升机雷电间接效应数值仿真[J]. 强激光与粒子束, 2015, 27:083205. (Huang Liyang, Chen Xiaoning, Guo Fei, et al. Numerical simulation of lightning indirect effects on helicopter[J]. High Power Laser and Particle Beams, 2015, 27: 083205 doi: 10.11884/HPLPB201527.083205
    [8] 黄邦菊, 肖尚辉. 超宽带通信信号对GPS接收机的干扰研究[J]. 信息工程大学学报, 2006(3):237-240. (Huang Bangju, Xiao Shanghui. Research on interference of UWB signal to GPS receivers[J]. Journal of Information Engineering University, 2006(3): 237-240 doi: 10.3969/j.issn.1671-0673.2006.03.009
    [9] Apra M, D'Amore M, Gigliotti K, et al. Lightning indirect effects certification of a transport aircraft by numerical simulation[J]. IEEE Trans Electromagnetic Compatibility, 2008, 50(3): 513-523. doi: 10.1109/TEMC.2008.927738
    [10] Perrin E, Tristant F, Guiffaut C, et al. A numerical tool to estimate lightning indirect effects on a composite aircraft[C]//30th International Conference on Lightning Protection (ICLP). 2011.
    [11] 黄军玲. 飞机雷电间接效应仿真与研究[D]. 成都: 西南交通大学, 2016.

    Huang Junling. Simulation and research of lightning indirect effects on the aircraft[D]. Chengdu: Southwest Jiaotong University, 2016.
    [12] 赵铜城, 余道杰, 周东方, 等. 无人机GPS接收机超宽谱电磁脉冲效应与试验分析[J]. 强激光与粒子束, 2019, 31:023001. (Zhao Tongcheng, Yu Daojie, Zhou Dongfang, et al. Ultra-wide spectrum electromagnetic pulse effect and experimental analysis of UVA GPS receiver[J]. High Power Laser and Particle Beams, 2019, 31: 023001 doi: 10.11884/HPLPB201931.180365
    [13] 张智香, 刘小龙, 陈锦, 等. 高重频超宽谱短电磁脉冲对GPS接收机干扰[J]. 强激光与粒子束, 2014, 26:033006. (Zhang Zhixiang, Liu Xiaolong, Chen Jin, et al. Interference of ultra-wideband short electromagnetic pulses of high repetition frequency to GPS receiver[J]. High Power Laser and Particle Beams, 2014, 26: 033006 doi: 10.3788/HPLPB20142603.33006
    [14] SAE-ARP-5412. Aircraft lightning environment and related test waveform[S].
    [15] 赵涛宁, 刘顺坤. 飞机雷电间接效应试验方法[J]. 上海计量测试, 2018, 45(s1):6-10, 14. (Zhao Taoning, Liu Shunkun. Study of the lightning indirect effects test technique on aircraft[J]. Shanghai Measurement and Testing, 2018, 45(s1): 6-10, 14
  • 加载中
图(15) / 表(2)
计量
  • 文章访问数:  1177
  • HTML全文浏览量:  305
  • PDF下载量:  133
  • 被引次数: 0
出版历程
  • 收稿日期:  2020-09-14
  • 修回日期:  2020-11-13
  • 网络出版日期:  2021-03-30
  • 刊出日期:  2021-03-05
