9.5 m高水平极化有界波电磁脉冲模拟器内场分布特性的初步实验研究

吴伟 王海洋 吴刚 朱湘琴 肖晶 程乐

吴伟, 王海洋, 吴刚, 等. 9.5 m高水平极化有界波电磁脉冲模拟器内场分布特性的初步实验研究[J]. 强激光与粒子束. doi: 10.11884/HPLPB202133.200303
引用本文: 吴伟, 王海洋, 吴刚, 等. 9.5 m高水平极化有界波电磁脉冲模拟器内场分布特性的初步实验研究[J]. 强激光与粒子束. doi: 10.11884/HPLPB202133.200303
Wu Wei, Wang Haiyang, Wu Gang, et al. Preliminary experimental investigation of field distribution characteristics in horizontal polarized bounded-wave EMP simulator with 9.5 m height[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202133.200303
Citation: Wu Wei, Wang Haiyang, Wu Gang, et al. Preliminary experimental investigation of field distribution characteristics in horizontal polarized bounded-wave EMP simulator with 9.5 m height[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202133.200303

9.5 m高水平极化有界波电磁脉冲模拟器内场分布特性的初步实验研究

doi: 10.11884/HPLPB202133.200303
基金项目: 强脉冲辐射环境模拟与效应国家重点实验室专项经费资助项目(SKLIPR1601Z)
详细信息
    作者简介:

    吴伟:吴 伟(1976—),男,博士,高级工程师,主要从事研究方向为电磁脉冲技术及效应、抗辐射加固技术等方向的研究工作;ww@163.com

  • 中图分类号: TN011; O441.3

Preliminary experimental investigation of field distribution characteristics in horizontal polarized bounded-wave EMP simulator with 9.5 m height

  • 摘要: 测量了9.5 m高的水平极化有界波电磁脉冲模拟器的内部场,并根据实验测量结果分析了该模拟器内场分布特性,包括一定区域内场均匀性的定量分析及模拟器内部有效测试空间的确定方法,进而对最低位置为距离地面2 m的有效测试空间进行了预估。实验结果表明:位于该模拟器双锥中心正下方且距离该中心5.5~7.5 m的测点场的峰值基本按照与中心间距的倒数衰减,且随着测点与双锥中心间距的增大,因锥与极板不连续结构导致的波形变化在时间轴上滞后,而因地面影响导致的波形变化在时间轴上提前;在距离地面比较高的水平面上,两极板之间场的外泄方向场的衰减比双锥中轴线方向场的衰减更慢;该模拟器内部距离地面2 m的水平面上12 m×12 m的区域内所取测点的归一化场平均峰值约为0.678,归一化场平均峰值的标准偏差约为0.068 9,场的均匀性约为2.039 dB。
  • 图  1  9.5 m高的EMP模拟器

    Figure  1.  EMP simulator with 9.5 m height

    图  2  EMP模拟器双锥实体图

    Figure  2.  EMP simulator’s bi-cones

    图  3  实验测得的EMP模拟器的激励电压波形

    Figure  3.  EMP simulator’s source voltage from experiment

    图  4  位于双锥正下方的几个测点场的归一化时域波形

    Figure  4.  Normalized Ez of some points below bi-cones’ center in time-domain

    图  5  模拟器内部某水平面上沿坐标轴偏离中心的几个测点位置

    Figure  5.  Location of testing-points along x-axis or z-axis away the center on some horizontal plane in simulator

    图  6  距离地面3 m高的水平面上沿x轴及z轴偏离水平面中心的测点场归一化时域波形的对比

    Figure  6.  Comparison of normalized Ez of some points located away from the center of the horizontal plane with h =3 m along x-axis and z-axis

    表  1  沿着x轴或者z轴偏离水平面中心的测点场归一化峰值的比较

    Table  1.   Comparison of peak-values of normalized Ez at points away from the center of some horizontal plane

    h/mpoint’s location/mnormalized peak-valuerise-time/nsFWHM/ns
    2(2,7.5,0)0.7382.2813.16
    2(4,7.5,0)0.7192.2012.87
    2(6,7.5,0)0.6522.5310.80
    2(0,7.5,2)0.7242.2013.40
    2(0,7.5,4)0.7202.3012.83
    2(0,7.5,6)0.6001.8012.07
    3(2,6.5,0)0.8192.1619.76
    3(4,6.5,0)0.7382.2918.60
    3(6,6.5,0)0.6622.3518.20
    3(0,6.5,2)0.7922.4419.24
    3(0,6.5,4)0.7532.1718.94
    3(0,6.5,6)0.6092.7516.60
    4(2,5.5,0)0.8782.3125.63
    4(4,5.5,0)0.8342.8324.29
    4(6,5.5,0)0.7352.4622.83
    4(0,5.5,2)0.8012.3725.09
    4(0,5.5,4)0.7702.8324.11
    4(0,5.5,6)0.6242.5121.66
    下载: 导出CSV

    表  2  距离地面2 m的水平面上若干测点场的归一化峰值

    Table  2.   Peak-values of normalized Ez at points on the horizontal plane with h=2 m

    point’s location/mnormalized peak-value
    (0,7.5,0)0.745
    (0,7.5,2)0.724
    (0,7.5,4)0.720
    (0,7.5,6)0.600
    (2,7.5,2)0.722
    (2,7.5,0)0.738
    (4,7.5,0)0.719
    (6,7.5,0)0.652
    (4,7.5,4)0.609
    (6,7.5,6)0.553
    下载: 导出CSV
  • [1] Baum C E. EMP simulators for various types of nuclear EMP environments: an interim categorization[J]. IEEE Transactions on Antennas and Propagation, 1978, 26(1): 35-53. doi: 10.1109/TAP.1978.1141794
    [2] Baum C E. Review of hybrid and equivalent-electric-dipole EMP simulators[R]. Sensor and Simulation Note 277, 1982.
    [3] 孙凤杰, 罗学金, 李小伟, 等. 亚纳秒前沿有界波模拟器传输线设计的理论分析与实验[J]. 强激光与粒子束, 2008, 20(5):811-814. (Sun Fengjie, LuoXuejin, Li Xiaowei, et al. Theoretical analysis and experimental varification on design of transmission line for subnanosecondrisetime EMP simulator[J]. High Power Laser and Particle Beams, 2008, 20(5): 811-814
    [4] 田春明, 王建国, 陈雨生, 等. 基于TEM喇叭的辐射波模拟器天线的近场特性[J]. 强激光与粒子束, 2004, 16(5):641-644. (TianChunming, Wang Jianguo, Chen Yusheng, et al. Near-field characteristics of radiating-wave simulator antenna based on TEM horn[J]. High Power Laser and Particle Beams, 2004, 16(5): 641-644
    [5] Giri D V, Baum C E. Design guidelines for flat-plate conical guided-wave EMP simulators with distributed terminators[R]. Sensor and Simulation Note 402, 1996.
    [6] 谢彦召, 相辉, 聂鑫, 等. 不对称结构的分布式负载有界波电磁脉冲模拟器[J]. 强激光与粒子束, 2006, 18(10):1669-1672. (XieYanzhao, Xiang Hui, NieXin, et al. Design and construction of an asymmetrical bounded wave EMP simulator with distributed terminators[J]. High Power Laser and Particle Beams, 2006, 18(10): 1669-1672
    [7] 潘晓东, 魏光辉, 任新智. 有界波模拟器内部电场分布仿真研究[J]. 测试技术学报, 2007, 21(5):410-413. (Pan Xiaodong, Wei Guanghui, RenXinzhi. Simulation research on electric field distribution in bounded-wave simulator[J]. Journal of Test and Measurement Technology, 2007, 21(5): 410-413
    [8] 李云伟, 王泽忠, 刘峰. 有界波电磁脉冲模拟器参数对传播模式的影响[J]. 高电压技术, 2007, 33(5):54-57. (Li Yunwei, Wang Zezhong, Liu Feng. Influence of parameters of boundary electromagnetic pulse simulator on transmitting mode[J]. High Voltage Engineering, 2007, 33(5): 54-57
    [9] 国海广, 魏光辉, 范丽思, 等. 快沿电磁脉冲模拟器内部垂直极化场分布仿真研[J]. 强激光与粒子束, 2009, 21(3):403-406. (GuoHaiguang, Wei Guanghui, Fan Lisi, et al. Simulation study on vertical field distribution of EMP simulator with fast risetime[J]. High Power Laser and Particle Beams, 2009, 21(3): 403-406
    [10] 杜立航, 高成, 陈海林, 等. 金属挡板对平行线栅有界波模拟器的影响仿真研究[J]. 强激光与粒子束, 2018, 30:073204. (Du Lihang, Gao Cheng, Chen Hailin, et al. Simulation study on influence of metal plate on parallel wire-grid bounded-wave simulator[J]. High Power Laser and Particle Beams, 2018, 30: 073204
    [11] 朱湘琴, 陈再高, 吴伟, 等. 离散电阻加载的大型垂直极化EMP辐射波模拟器的并行FDTD模拟[J]. 计算物理, 2019, 36(3):349-356. (Zhu Xiangqin, Chen Zaigao, Wu Wei, et al. Simulation of large vertically polarized EMP radiating wave simulator with discrete resistors using parallel FDTD method[J]. Chinese Journal of Computational Physics, 2019, 36(3): 349-356
    [12] 谢秦川, 陈明, 李进玺, 等. 水平极化电磁脉冲模拟器空间场的数值模拟[J]. 强激光与粒子束, 2004, 16(10):1304-1306. (Xie Qinchuan, Chen Ming, Li Jinxi, et al. Numerical simulation of space-time distribution of field of horizontally polarized electromagnetic pulse simulators[J]. High Power Laser and Particle Beams, 2004, 16(10): 1304-1306
    [13] 朱湘琴, 王建国, 蔡利兵, 等. 辐射波电磁脉冲模拟器笼形天线辐射特性的并行计算[J]. 强激光与粒子束, 2011, 23(6):1597-1601. (Zhu Xiangqin, Wang Jianguo, CaiLibing, et al. Parallel computation for radiation characteristics of cage antenna of radiating-wave EMP simulator[J]. High Power Laser and Particle Beams, 2011, 23(6): 1597-1601 doi: 10.3788/HPLPB20112306.1597
    [14] 朱湘琴, 吴伟, 王海洋. 大型双锥椭圆笼形天线关键参数的影响分析[J]. 电波科学学报, 2021, 36(1):127-135. (Zhu Xiangqin, Wu Wei, Wang Haiyang. The effect analysis of key parameters of large biconical-ellipsoid cage antenna[J]. Chinese Journal of Radio Science, 2021, 36(1): 127-135
    [15] 毛从光, 周辉. 辐射波HEMP模拟器关键参数数值分析[J]. 核电子学与探测技术, 2009, 29(6):1348-1352. (Mao Congguang, Zhou Hui. Key parameters analysis of hybrid HEMP simulator[J]. Nuclear Electronics & Detection Technology, 2009, 29(6): 1348-1352
    [16] Bailey V, Carboni V, Eichenberger C, et al. A 6-MV pulser to drive horizontally polarized EMP simulators[J]. IEEE Transactions on Plasma Science, 2010, 38(10): 2254-2258.
    [17] 朱湘琴, 吴伟, 张国伟, 等. 大型水平极化电磁脉冲有界波模拟器的并行模拟分析[J]. 计算物理, 2019, 36(6):691-698. (Zhu Xiangqin, Wu Wei, Zhang Guowei, et al. Parallel simulation and analysis of large EMP bounded wave simulator with horizontal polarization[J]. Chinese Journal of computational Physics, 2019, 36(6): 691-698
    [18] 朱湘琴, 吴伟, 王海洋. 大型水平极化电磁脉冲有界波模拟器的辐射场分布特性分析[J]. 现代应用物理, 2020, 11:040502. (Zhu Xiangqin, Wu Wei, Wang Haiyang. Characteristics of radiation electric field distribution in large EMP bounded wave simulator with horizontal polarization[J]. Modern Applied Physics, 2020, 11: 040502
    [19] IEC61000-4-25. Testing and measurement techniques; high-altitude electromagnetic impulse HEMP simulator compendium[S].
    [20] 卢万铮. 天线理论与技术[M]. 西安: 西安电子科技大学出版社, 2004.

    Lu Wanzheng. Antenna theory and techniques[M]. Xi’an: Xidian University Press, 2004.
    [21] Groh G, Karst J P, Koch M, et al. TEM waveguides for EMC measurements[J]. IEEE Transactions on Electromagnetic Compatibility, 1999, 41(4): 440-445. doi: 10.1109/15.809846
