中国散裂中子源准直控制网数据处理方法

王铜; 董岚; 梁静; 马娜; 柯志勇; 何振强; 罗涛; 门玲鸰; 闫路平; 韩圆颖; 卢尚; 张露彦; 闫皓月; 刘晓阳

doi:10.11884/HPLPB202133.210096

中国散裂中子源准直控制网数据处理方法

doi: 10.11884/HPLPB202133.210096

王铜^{1, 2, 3, 4,},
董岚^{1, 2},
梁静^{1, 2, ,},
马娜^{1, 2},
柯志勇^{1, 2},
何振强^{1, 2},
罗涛^{1, 2},
门玲鸰^{1, 2},
闫路平^{1, 2},
韩圆颖^{1, 2},
卢尚^{1, 2},
张露彦^{1, 2},
闫皓月^{1, 2},
刘晓阳^{1, 2}

1.
中国科学院高能物理研究所，北京 100049
2.
散裂中子源科学中心，广东东莞 523803
3.
中国科学院微电子研究所，北京 100029
4.
中国科学院大学，北京 100049

基金项目: 国家自然科学基金项目（12075264）

详细信息

作者简介:
王　铜，wangt@ihep.ac.cn

通讯作者:
梁　静，liangjing@ihep.ac.cn

中图分类号: TL505
计量
- 文章访问数: 1012
- HTML全文浏览量: 295
- PDF下载量: 46
- 被引次数: 0
出版历程
- 收稿日期: 2021-03-20
- 修回日期: 2021-09-16
- 网络出版日期: 2021-09-14
- 刊出日期: 2021-10-15

1.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
2.
Spallation Neutron Source Science Center, Dongguan 523803, China
3.
Institute of Microelectronics, Chinese Academy of Sciences, Beijing 100029, China
4.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 以中国散裂中子源CSNS的直线加速器控制网为例，对其数据处理方法进行研究，采用平面与高程二维平差以及三维定向平差两种方式对准直控制网进行处理分析。同时，为了使准直数据处理更加简易便利，提出利用激光跟踪仪的测量软件SA实现三维定向平差的方法。通过不同软件及不同数据处理方法的对比，验证准直控制网数据处理的正确性，最终200 m长直线控制网点位精度优于0.2 mm，这为准直控制网的数据处理提供了指导。
- 粒子加速器准直 /
- 激光跟踪仪 /
- 控制网 /
- 平差处理 /
- 精度分析
Abstract: Control network is the reference of equipment installation and alignment, so the adjustment processing of control network is very important. In this paper, the data processing methods of separate plane and elevation adjustment and three-dimensional adjustment were studied in LINAC of China Spallation Neutron Source. Meanwhile, to make the data processing more simple and convenient, SA software was introduced to realize three-dimensional adjustment with the gravity orientation constrained. Through the comparison of different software and different data processing methods, correctness of the data processing of the control network is verified. Finally, the accuracy of the 200 m linear control network was better than 0.2 mm, which provides guidance for data processing of control network for alignment.
- alignment of particle accelerator /
- laser tracker /
- control network /
- adjustment /
- accuracy analysis

HTML全文

图 1 CSNS装置坐标系定义

Figure 1. Definition of the facility coordinate system of CSNS

下载: 全尺寸图片幻灯片

图 2 跟踪仪单站测量示意图

Figure 2. Sketch of laser tracker measurement in single station

下载: 全尺寸图片幻灯片

图 3 Vector平差得到直线隧道控制网点的点位精度

Figure 3. Points accuracy of control points processed by Vector

下载: 全尺寸图片幻灯片

图 4 SA平差得到直线隧道控制网点的点位精度

Figure 4. Point accuracy of control points processed by SA

下载: 全尺寸图片幻灯片

图 5 两种软件坐标差值对比

Figure 5. Deviation of point coordinates between two softwares

下载: 全尺寸图片幻灯片

表 1 直线永久点在装置坐标系下的坐标

Table 1. Coordinates of permanent points of LINAC

point name X/m Y/m Z/m

P₀₁ −232.301862 57.287562 42.426850
P₀₂ −30.157759 56.972985 42.740203

下载: 导出CSV
