波导-同轴线的脊型转换器设计与测试

张辉 慕振成 荣林艳 王博 万马良 谢哲新 周文中 李松 刘美飞

张辉, 慕振成, 荣林艳, 等. 波导-同轴线的脊型转换器设计与测试[J]. 强激光与粒子束, 2021, 33: 103003. doi: 10.11884/HPLPB202133.210105
引用本文: 张辉, 慕振成, 荣林艳, 等. 波导-同轴线的脊型转换器设计与测试[J]. 强激光与粒子束, 2021, 33: 103003. doi: 10.11884/HPLPB202133.210105
Zhang Hui, Mu Zhencheng, Rong Linyan, et al. Design and test of device for transition from ridge waveguide to coaxial line[J]. High Power Laser and Particle Beams, 2021, 33: 103003. doi: 10.11884/HPLPB202133.210105
Citation: Zhang Hui, Mu Zhencheng, Rong Linyan, et al. Design and test of device for transition from ridge waveguide to coaxial line[J]. High Power Laser and Particle Beams, 2021, 33: 103003. doi: 10.11884/HPLPB202133.210105

波导-同轴线的脊型转换器设计与测试

doi: 10.11884/HPLPB202133.210105
详细信息
    作者简介:

    张 辉,zhanghui@ihep.ac.cn

  • 中图分类号: TN015

Design and test of device for transition from ridge waveguide to coaxial line

  • 摘要: 射频测量系统中经常会用到波导-同轴线转换器,主要是利用其将射频器件的波导端口转换成能够直接接入测量仪器的50 Ω同轴线。本文设计的648 MHz/WR1500波导同轴转换器主要用于CSNS升级工程(CSNS-II)超导直线射频器件的测量。利用切比雪夫脊型阶梯阻抗变换和探针耦合的方式实现波导到同轴线的转换。对脊加载波导和不连续同轴线分别进行了分析,得到最优尺寸。为了提高测量精度,设计的波导-同轴线转换器具有低插入损耗、低驻波比和宽带宽等特性。最后对生产的转换器进行了测试,测试结果与仿真结果相近,能够满足作为测量器件的使用要求。
  • 图  1  脊波导-同轴线转换器示意图

    Figure  1.  Schematic diagram of ridge waveguide to coaxial transition

    图  2  脊厚度对回波损耗的影响

    Figure  2.  Influence of thickness on return loss

    图  3  脊的位置对回波损耗的影响

    Figure  3.  Influence of location on return loss

    图  4  不连续性同轴线及其等效电路

    Figure  4.  Discontinuous coaxial line and its equivalent circuit

    图  5  不连续电容Cd曲线(α=a/b

    Figure  5.  Discontinuous capacitance Cd curve

    图  6  不同间隙半径比a/b情况下的回波损耗

    Figure  6.  Return loss with different a/b

    图  7  探针半径对回波损耗的影响

    Figure  7.  Influence of radius on return loss

    图  8  探针长度对回波损耗的影响

    Figure  8.  Influence of length on return loss

    图  9  脊波导和同轴线的电场分布

    Figure  9.  Distribution of electric field in ridge waveguide and coaxial line

    图  10  S参数仿真曲线

    Figure  10.  S parameters simulation curve

    图  11  (a)转换器纵向切面图,(b)聚四氟乙烯加工图,(c)内导体及探针加工图

    Figure  11.  (a) Cross section of transition,(b) teflon machining dimension and (c) inner conductor and probe machining dimension

    图  12  (a)转换器侧视图及探针,(b)转换器正视图及脊

    Figure  12.  (a) Side view of transition and probe,(b) front view of transition and ridge

    图  13  实际产品测试曲线

    Figure  13.  Product test curves

  • [1] 张健穹, 刘庆想, 李相强, 等. 三角形栅格矩形径向线螺旋阵列天线的设计与实验研究[J]. 强激光与粒子束, 2009, 21(4):550-554. (Zhang Jianqiong, Liu Qingxiang, Li Xiangqiang, et al. Design and experimental research on triangle-grid radial-line helical rectangular array antenna[J]. High Power Laser and Particle Beams, 2009, 21(4): 550-554
    [2] 王文祥. 微波工程技术[M]. 北京: 国防工业出版社, 2009.

    Wang Wenxiang. Microwave engineering technology[M]. Beijing: National Defense Industry Press, 2009
    [3] Eric H. Essentials of RF and microwave grounding[M]. Boston: Artech House, 2006.
    [4] Gupta K C. Microstrip lines and slotlines [M]. 2nd ed. Norwood MA: Artech House, 2006.
    [5] Yao Huiwen, Amr A, Ji F L, et al. A full wave analysis of microstrip to waveguide transitions[J]. IEEE Transactions on Microwave Theory and Techniques, 1994, 42(12): 213-216.
    [6] 张克潜, 李德杰. 微波与光电子学中的电磁理论[M]北京: 电子工业出版社. 2001.

    Zhang Keqian, Li Dejie. Electromagnetic theory in microwave and optoelectronics[M]. Beijing: Publishing House of Electronics Industry, 2001
    [7] Malik Z Y, Abdul M, Muhammad I N, et al. Narrow band ridge waveguide-to-microstrip transition for low noise amplifier at Ku-band[C]//Proceedings of International Bhurban Conference on Applied Sciences & Technology Islamabad. 2009: 140-143
    [8] Yang Rugui. Electromagnetic field and electromagnetic wave[M]. Beijing: Higher Education Press, 2005.
    [9] David M P. 微波工程[M]. 北京: 电子工业出版社, 2017.

    David M P. Microwave engineering[M]. Beijing: Publishing House of Electronics Industry, 2017
    [10] Skolnik M I. Radar handbook[M]. New York: McGraw Hill, 1990.
    [11] 同轴线中被补偿不连续性的反射系数曲线系以及最佳尺寸的确定[J]. 无线电工程译文, 1971(2): 85-98.

    Determination of reflection coefficient curve system and optimal size of compensated discontinuity in coaxial line[J]. Radio Engineering, 1971(2): 85-98
    [12] Whinnery J R, Jamieson H W. Equivalent circuits for discontinuities in transmission lines[C]//Proceedings of the I. R. E. 1944: 98-114
    [13] 柯林 R. E. 微波工程基础[M]. 北京: 人民邮电出版社, 1981.

    Colin R E. Fundamentals of microwave engineering[M]. Beijing: People’s Posts and Telecommunications Publishing House, 1981
