Design of low-scattering transmissive lens based on integration of absorption with focusing
-
摘要: 通过传输型超表面透镜与电路模拟雷达波吸收器的集成设计，提出了一种兼具透射波前变换与带外雷达散射截面减缩特性的微波复合材料设计方法。透镜采用亚波长分布的周期性单元，由梯度相位补偿对透射波进行调节，进而获得平面波前与球面波前之间的互易变换。并且，使用透镜在波前变换频带以外低频端的反射特征，结合单个有耗层设计，构造了电路模拟吸波器。选用一副缝隙耦合馈电的微带贴片天线单元作为初级馈源天线，观察到复合材料的波前变换特性可在宽频带范围内产生主瓣增益增强效果。与透镜相比，电路模拟吸波器的引入使得复合材料针对TE与TM极化分别可在130.68%与155.11%的频率范围内获得雷达散射截面减缩效果。通过全波模拟和实验测量，验证了辐射增益增强与雷达散射截面减缩效果，表明了复合材料吸聚一体设计的有效性。Abstract: Based on the integration of a transmissive metasurface lens with the circuit analog absorber, the design of a microwave composite material with characteristics of both transmissive wavefront conversion and out-of-band radar cross-section reduction is proposed and examined. With the refraction tuned by gradient phase compensation, the lens consisting of sub-wavelength spaced layers of periodic inclusions exhibits a reciprocal conversion between planar and spherical wavefronts. Moreover, the responses of the lens at the lower side of the wavefront conversion band are used to construct a circuit analog absorption profile containing one lossy layer. By using an aperture-coupled microstrip patch antenna element as the primary feeding antenna, main lobe gain enhancement over a wide band is observed as a result of the wavefront conversion of the composite material. In comparison with the lens, the introduction of the circuit analog absorption profile produces radar cross-section reduction over the bandwidths of 130.68% and 155.11% for TE and TM polarizations, respectively. The full-wave simulation and experimental measurement demonstrate the enhanced radiation gain and reduced radar cross-section and illustrate the validity of the composite material design with integrated absorption and focusing.
-
图 1 复合阵列结构的层状剖面示意图
Figure 1. Schematic description of the layered composite array structure profile
图 4 透镜单元在正入射时的透射与反射仿真结果
Figure 4. Simulated transmission and reflection of the lens inclusion under normal incidence
图 5 置于金属导电板上方的有耗层单元结构及其反射系数幅度仿真结果
Figure 5. Inclusion geometry of the lossy layer placed above a conducting plate and the simulated reflection magnitude
图 7 复合阵列结构在TE极化正入射时的透射电场幅度分布
Figure 7. Electric field amplitude distribution generated by the composite array under TE-polarized normal incidence
图 8 金属导电平板、透镜、以及复合阵列结构在TE或TM极化正入射时的散射电场分布
Figure 8. Scattered electric field distribution of a conducting plate, the lens and the composite array under TE-polarized or TM-polarized normal incidence
图 9 初级馈源天线及其与复合阵列结构的位置关系
Figure 9. Freestanding feeding antenna and its location under the composite array.
图 10 初级馈源天线以及经覆盖后的初级馈源天线的辐射仿真结果
Figure 10. Simulated radiation results of the feeding antenna without or with the composite array cover
图 12 经透镜或复合阵列结构所覆盖的初级馈源天线的雷达散射截面仿真结果
Figure 12. Simulated scattering cross-section of the feeding antenna covered with the lens or the composite array
图 13 复合阵列结构及初级馈源天线样件照片
Figure 13. Photo of the fabricated antenna element covered with the composite array
图 14 初级馈源天线样件在无或有复合阵列结构样件覆盖时的输入反射系数幅度仿真与实验结果
Figure 14. Simulated and measured reflection coefficient of the feeding antenna without or with the composite array cover
图 15 初级馈源天线样件在无或有复合阵列结构样件覆盖时的主瓣增益仿真与实验结果
Figure 15. Simulated and measured boresight gain of the feeding antenna without or with the composite array cover
-
[1] Munk B A. Frequency selective surfaces: Theory and design[M]. New York: John Wiley & Sons, 2000. [2] Chiu C N, Kuo C H, Lin M S. Bandpass shielding enclosure design using multipole-slot arrays for modern portable digital devices[J]. IEEE Transactions on Electromagnetic Compatibility, 2008, 50(4): 895-904. doi: 10.1109/TEMC.2008.2004560 [3] Wang Linbiao, See K Y, Zhang Junwu, et al. Ultrathin and flexible screen-printed metasurfaces for EMI shielding applications[J]. IEEE Transactions on Electromagnetic Compatibility, 2011, 53(3): 700-705. doi: 10.1109/TEMC.2011.2159509 [4] 王向峰, 高炳攀, 任志英, 等. 一体化曲面共形频率选择表面雷达罩[J]. 光学 精密工程, 2018, 26(6):1362-1369. (Wang Xiangfeng, Gao Binpan, Ren Zhiying, et al. Integrated curved-surface conformal frequency selective surface radome[J]. Optics and Precision Engineering, 2018, 26(6): 1362-1369 doi: 10.3788/OPE.20182606.1362 [5] 李姣, 乔学增, 骆兴芳. 一种多频段可调复合单元频率选择表面的设计[J]. 电子测量技术, 2010, 33(12):24-28. (Li Jiao, Qiao Xuezeng, Luo Xingfang. Design of frequency selective surfaces with adjustable compounded unit cell and multi-band[J]. Electronic Measurement Technology, 2010, 33(12): 24-28 doi: 10.3969/j.issn.1002-7300.2010.12.007 [6] 王珊珊, 高劲松, 梁凤超, 等. 多频段十字分形频率选择表面[J]. 物理学报, 2011, 60:050703. (Wang Shanshan, Gao Jinsong, Liang Fengchao, et al. Multiband fractal cross dipole frequency selective surface[J]. Acta Physica Sinica, 2011, 60: 050703 [7] Yadav S, Jain C P, Sharma M M. Smartphone frequency shielding with penta-bandstop FSS for security and electromagnetic health applications[J]. IEEE Transactions on Electromagnetic Compatibility, 2019, 61(3): 887-892. doi: 10.1109/TEMC.2018.2839707 [8] Sampath S S, Sivasamy R. A single-layer UWB frequency-selective surface with band-stop response[J]. IEEE Transactions on Electromagnetic Compatibility, 2020, 62(1): 276-279. doi: 10.1109/TEMC.2018.2886285 [9] Yin Weiyang, Zhang Hou, Zhong Tao, et al. Ultra-miniaturized low-profile angularly-stable frequency selective surface design[J]. IEEE Transactions on Electromagnetic Compatibility, 2019, 61(4): 1234-1238. doi: 10.1109/TEMC.2018.2881161 [10] Sampath S S, Sivasamy R, Kumar K J J. A novel miniaturized polarization independent band-stop frequency selective surface[J]. IEEE Transactions on Electromagnetic Compatibility, 2019, 61(5): 1678-1681. doi: 10.1109/TEMC.2018.2869664 [11] 郑光明, 王雪纯, 汪岩. 小型化宽阻带多层宽带频率选择表面研究[J]. 华中科技大学学报(自然科学版), 2020, 48(8):57-60. (Zheng Guangming, Wang Xuechun, Wang Yan. Study on miniaturized ultra wide stopband multilayer broadband frequency selective surface[J]. Journal of Huazhong University of Science and Technology(Nature Science Edition), 2020, 48(8): 57-60 doi: 10.13245/j.hust.200810 [12] Paiva S B, Neto V P S, D'Assunção A G. A new compact, stable, and dual-band active frequency selective surface with closely spaced resonances for wireless applications at 2.4 and 2.9 GHz[J]. IEEE Transactions on Electromagnetic Compatibility, 2020, 62(3): 691-697. doi: 10.1109/TEMC.2019.2918568 [13] Sivasamy R, Moorthy B, Kanagasabai M, et al. A wideband frequency tunable FSS for electromagnetic shielding applications[J]. IEEE Transactions on Electromagnetic Compatibility, 2018, 60(1): 280-283. doi: 10.1109/TEMC.2017.2702572 [14] Ghosh S, Srivastava K V. Broadband polarization-insensitive tunable frequency selective surface for wideband shielding[J]. IEEE Transactions on Electromagnetic Compatibility, 2018, 60(1): 166-172. [15] Zhang Liang, Yang Guohui, Wu Qun, et al. A novel active frequency selective surface with wideband tuning range for EMC purpose[J]. IEEE Transactions on Magnetics, 2012, 48(11): 4534-4537. [16] 薛凤至, 伍瑞新, 徐成, 等. 利用小型化频率选择表面实现宽带电磁透明[J]. 压电与声光, 2019, 41(4):465-468. (Xue Fengzhi, Wu Ruixin, Xu Cheng, et al. Using miniaturized frequency selective surface to realize broadband electromagnetic transparency[J]. Piezoelectrics & Acoustooptics, 2019, 41(4): 465-468 doi: 10.11977/j.issn.1004-2474.2019.04.001 [17] Choi W H, Shin J H, Song T H, et al. Design of circuit-analog (CA) absorber and application to the leading edge of a wing-shaped structure[J]. IEEE Transactions on Electromagnetic Compatibility, 2014, 56(3): 599-607. doi: 10.1109/TEMC.2013.2290057 [18] He Yun, Feng Weisen, Guo Sai, et al. Design of a dual-band electromagnetic absorber with frequency selective surfaces[J]. IEEE Antennas and Wireless Propagation Letters, 2020, 19(5): 841-845. doi: 10.1109/LAWP.2020.2981729 [19] Edries M, Mohamed H A, Hekal S S, et al. A new compact quad-band metamaterial absorber using interlaced I/Square resonators: design, fabrication, and characterization[J]. IEEE Access, 2020, 17: 143723-143733. [20] Shang Yuping, Shen Zhongxiang, Xiao Shaoqiu. On the design of single-layer circuit analog absorber using double-square-loop array[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(12): 6022-6029. doi: 10.1109/TAP.2013.2280836 [21] Chen Jianlin, Shang Yuping, Liao Cheng. Double-layer circuit analog absorbers based on resistor-loaded square-loop arrays[J]. IEEE Antennas and Wireless Propagation Letters, 2018, 17(4): 591-595. doi: 10.1109/LAWP.2018.2805333 [22] Baskey H B, Johari E, Akhtar M J. Metamaterial structure integrated with a dielectric absorber for wideband reduction of antennas radar cross section[J]. IEEE Transactions on Electromagnetic Compatibility, 2017, 59(4): 1060-1069. doi: 10.1109/TEMC.2016.2639060 [23] Bilotti F, Toscano A, Alici K B, et al. Design of miniaturized narrowband absorbers based on resonant-magnetic inclusions[J]. IEEE Transactions on Electromagnetic Compatibility, 2011, 53(1): 63-72. doi: 10.1109/TEMC.2010.2051229 [24] 段坤, 唐守柱. 一种宽通带低插损的吸透一体频率选择表面[J]. 现代雷达, 2020, 42(4):72-76. (Duan Kun, Tang Shouzhu. A wide passband and low insertion loss frequency-selective resorber[J]. Modern Radar, 2020, 42(4): 72-76 [25] 赵宇婷, 李迎松, 杨国辉. 基于电路模拟吸收体的宽带吸波型频率选择表面设计[J]. 物理学报, 2020, 69:198101. (Zhao Yuting, Li Yingsong, Yang Guohui. A novel wideband absorptive frequency selective surface based on circuit analog absorber[J]. Acta Physica Sinic, 2020, 69: 198101 doi: 10.7498/aps.69.20200641 [26] 强宇, 周东方, 刘起坤, 等. 一种新型宽带吸收频率选择表面[J]. 强激光与粒子束, 2019, 31:103222. (Qiang Yu, Zhou Dongfang, Liu Qikun, et al. Novel absorptive frequency selective surface with wideband absorbing properties[J]. High Power Laser and Particle Beams, 2019, 31: 103222 doi: 10.11884/HPLPB201931.190210 [27] Shang Yuping, Shen Zhongxiang, Xiao Shaoqiu. Frequency-selective rasorber based on square-loop and cross-dipole arrays[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(11): 5581-5589. doi: 10.1109/TAP.2014.2357427 [28] Pang Yongqiang, Li Yongfeng, Qu Bingyue, et al. Wideband RCS reduction metasurface with a transmission window[J]. IEEE Transactions on Antennas and Propagation, 2020, 68(10): 7079-7087. doi: 10.1109/TAP.2020.2995429 [29] Shang Yuping, Lei Xue, Liao Cheng, et al. Frequency-selective structures with suppressed reflection through passive phase cancellation[J]. IEEE Transactions on Antennas and Propagation, 2020, 68(2): 1192-1197. doi: 10.1109/TAP.2019.2940495 [30] Shang Yuping, Xiao Shaoqiu, Tang Mingchun, et al. Radar cross-section reduction for a microstrip patch antenna using PIN diodes[J]. IET Microwaves Antennas & Propagation, 2012, 6(6): 670-679. doi: 10.1049/iet-map.2011.0460 -
