Beam dynamics calculation of cyclotron based on Geant4
-
摘要: 针对回旋加速器的束流动力学设计，基于Geant4模拟研究，提供一种可行的数值模拟方法。通过电磁场仿真软件Opera建立相应的电磁场数据导入到Geant4中进行插值计算，利用Geant4自带的电磁场微分方程与微分方程求解器计算粒子的平衡轨道，振荡频率以及加速轨道。其结果表明：对于横向运动而言，Geant4的计算结果与传统数值方法计算结果趋于一致；对于轴向运动而言，由于磁场插值方法的差异性，二者有一定的区别，对于在加速过程中的非平衡粒子，其能量变化围绕平衡粒子振荡。对于束损，通过限制粒子的运动时间，轴向位移加快计算效率，加入电极碰撞的判定使模拟更趋近实际情况。Abstract: Based on GEANT4 simulation, a feasible numerical simulation method is provided for the beam dynamics design of cyclotron. Through the electromagnetic field simulation software Opera, the corresponding electromagnetic field data are imported into GEANT4 for interpolation calculation. The equilibrium orbit, oscillation frequency and acceleration orbit of particles are calculated by using the electromagnetic field differential equation and differential equation solver of GEANT4. The results show that: for the transverse motion, GEANT4 calculation results and the traditional numerical method calculation results tend to be consistent; for the axial motion, due to the difference of the magnetic field interpolation method, there is a certain difference between the two. For the acceleration of the non-equilibrium particle, its energy changes around the equilibrium particle. For the beam loss, the simulation is closer to the actual experimental situation by limiting the particle motion time, accelerating the calculation efficiency by axial displacement and adding the determination of electrode collision.
-
Key words:
- cyclotron /
- Geant4 /
- simulation /
- Opera /
- beam dynamics
-
图 4 Geant4与CycSimulation闭轨差异
Figure 4. Comparison of closed orbit calculation between Geant4 and Cycsimulation
图 5 Geant4与CycSimulation横向和轴向振荡频率差异
Figure 5. Difference of betatron tunes between GEANT4 and Cycsimulation
图 7 Geant4模拟加速粒子与平衡粒子能量变化
Figure 7. GEANT4 simulates the energy changes of accelerating particles and equilibrium particles
表 1 LB-11物理参数
Table 1. Parameters of LB-11
structure name parameters value magnet hill gaps 3.8 cm RF Dee pole numbers 4 voltage 42 kV frequency 72.05 MHz ion source insert direction transverse slit area 2 mm2 extraction energy ～3 eV central region phase acceptance ＞40° extraction extraction method stripping extraction radius 40 cm
下载: 导出CSV
-
[1] 秦斌. 虚拟样机环境下的紧凑型回旋加速器物理设计[D]. 武汉: 华中科技大学, 2007Qin Bin. Design of compact cyclotrons in virtual prototyping environment[D]. Wuhan: Huazhong University of Science and Technology, 2007 [2] Smirnov V. Computer codes for beam dynamics analysis of cyclotronlike accelerators[J]. Physical Review Accelerators and Beams, 2017, 20(12): 124801. doi: 10.1103/PhysRevAccelBeams.20.124801 [3] Agostinelli S, Allison J, Amako K, et al. Geant4—a simulation toolkit[J]. Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, 2003, 506(3): 250-303. [4] Poole C M, Cornelius I, Trapp J V, et al. Fast tessellated solid navigation in GEANT4[J]. IEEE Transactions on Nuclear Science, 2012, 59(4): 1695-1701. doi: 10.1109/TNS.2012.2197415 [5] Poole C M, Cornelius I, Trapp J V, et al. A CAD interface for GEANT4[J]. Australasian Physical & Engineering Sciences in Medicine, 2012, 35(3): 329-334. [6] Roberts T J, Beard K B, Ahmed S, et al. G4beamline particle tracking in matter dominated beam line[C]//Proceedings of the Particle Accelerator, 24th Conference (PAC'11). 2011: 373-375. [7] Sato A. G4beamline simulation for the comet solenoid channel[C]//Proceedings of IPAC’10. 2010: 3449-3451. [8] Jones F W, Planche T, Rao Y N. Tracking in a cyclotron with Geant4[C]//Proceedings of Cyclotrons2013. 2013: 423-425. [9] 何小中, 杨国君, 龙继东, 等. 小型回旋加速器物理设计[C]//第二届全国核技术及应用研究学术研讨会大会论文摘要集. 2009: 836-841He Xiaozhong, Yang Guojun, Long Jidong, et al. Physical design of mini-type cyclotron[C]//National Symposium on Nuclear Technology and Applied Research. 2009: 836-841 [10] 姚红娟. CYCIAE-100回旋加速器轴向注入与中心区理论和实验研究[D]. 北京: 清华大学, 2008Yao Hongjuan. Theoretical and experimental study of the CYCIAE-100 cyclotron injection system and central region[D]. Beijing: Tsinghua University, 2008 [11] 唐靖宇, 魏宝文. 回旋加速器理论与设计[M]. 合肥: 中国科学技术大学出版社, 2008Tang Jingyu, Wei Baowen. Theory and design of cyclotrons[M]. Hefei: University of Science and Technology of China Press, 2008 -
