地闪通道底部回击速度的频变特性分析

厉燚翀 罗小军 张琪 邱实 石立华

厉燚翀, 罗小军, 张琪, 等. 地闪通道底部回击速度的频变特性分析[J]. 强激光与粒子束. doi: 10.11884/HPLPB202234.220185
引用本文: 厉燚翀, 罗小军, 张琪, 等. 地闪通道底部回击速度的频变特性分析[J]. 强激光与粒子束. doi: 10.11884/HPLPB202234.220185
Li Yichong, Luo Xiaojun, Zhang Qi, et al. Analysis on variation of return stroke velocity with frequency at the channel bottom of cloud to ground lightning[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202234.220185
Citation: Li Yichong, Luo Xiaojun, Zhang Qi, et al. Analysis on variation of return stroke velocity with frequency at the channel bottom of cloud to ground lightning[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202234.220185

地闪通道底部回击速度的频变特性分析

doi: 10.11884/HPLPB202234.220185
基金项目: 国家自然科学基金项目(51977219)
详细信息
    作者简介:

    厉燚翀,474170282@qq.com

    通讯作者:

    石立华,shilih@tom.com

  • 中图分类号: O441.6

Analysis on variation of return stroke velocity with frequency at the channel bottom of cloud to ground lightning

  • 摘要: 回击通道的光学观测对于研究回击发展过程和物理机制、完善工程回击模型都具有重要的意义。采用雷电发展过程高速光学观测系统(LiPOS)测量了人工引雷中距离通道底部21 m至309 m的一组通道发光波形,基于系统辨识的输出误差(OE)模型建立了回击向上传播过程光辐射脉冲间的传递函数,获得了1 kHz~1 MHz频段内群速度和相速度曲线。时域分析表明,通道辐射光脉冲波形前沿上升时间由靠近底部的1.1 μs变化为309 m高度处的1.84 μs,色散特性是其变化的重要原因。频域分析表明,OE模型能够有效抑制测量噪声的影响、获得清晰的分析曲线,100 kHz以下低频段内群速度呈显著的非单调变化,500 kHz以上区域群速度稳定在58%光速左右。将分析结果与相关文献的研究进行了对比和讨论。研究结果对于定量评价回击电流传播色散特性具有重要参考价值。
  • 图  1  LiPOS系统组成及实验设置

    Figure  1.  Components of LiPOS and experimental setup

    图  2  人工引雷通道底部光学观测记录

    Figure  2.  Optically observed records in the channel bottom of an artificially triggered lightning

    图  3  S5-S8的OE建模结果

    Figure  3.  Result of OE model for S5-S8

    图  4  OE建模获得的相速度和群速度

    Figure  4.  Phase and Group velocity obtained from OE model

    图  5  S5~S8的频谱密度分布

    Figure  5.  Spectrum density of channel S5~S8

    图  6  采用Heidler函数对文献[16]波形的拟合结果

    Figure  6.  Waveforms in [16] by Heidler function fitting

    图  7  OE方法处理结果与文献[16]结果的比较

    Figure  7.  Comparison of the results obtained by OE modeling with the curves given in [16]

    图  8  由图6波形计算得到的群速度和相速度曲线

    Figure  8.  Groupe velocity and phase velocities calculated from the waveforms given in Fig.6

    表  1  S5~S8的前沿上升时间

    Table  1.   Risetime of the waveforms of Channel S5~S8

    ChannelHeight (m)Rise Time (μs)
    S520.641.10
    S6116.641.32
    S7212.641.56
    S8308.641.84
    下载: 导出CSV

    表  2  不同传播高度对应的时域平均速度

    Table  2.   Risetime of the waveforms of Channel S5~S8

    IndicatorsTime Domain delay (μs)Time Domain speed (×108 m/s)
    Criterion10%50%Oblique
    Intercept
    10%50%Oblique
    Intercept
    S5-S6 0.52 0.52 0.50 1.85 1.85 1.92
    S5-S7 1.24 1.24 1.10 1.55 1.55 1.75
    S5-S8 1.98 2.18 1.86 1.45 1.32 1.55
    下载: 导出CSV
