Experimental research of 2 MV laser triggered gas switch
-
摘要: 介绍了2 MV激光触发多级气体开关在强光一号加速器上的实验研究工作。给出了实验方案，激光触发信号采用轴向引入的方法，激光光路穿过二极管，沿水线轴向引入开关；分析了开关自击穿实验和触发实验的实验结果，总结了实验中出现的问题并对其原因进行了分析，提出了改进措施。 结果表明，开关最大工作电压2 MV,最大电流大于600 kA，当欠压比88.3%时，激光触发开关的平均延时34.2 ns，抖动小于3.86 ns。Abstract: The paper presents the experimental investigation of laser triggered gas switch on Qiangguang-Ⅰ accelerator. In the experiments, the laser was transmitted along the axes of the water line through the diode. The results of self-breakdown experiments and trigger experiments are presented and analyzed. At the undervoltage ratio of 88.3%, the average delay of the laser triggered gas switch is 34.2 ns, and the time jitter is less than 3.86 ns, when the maximal operating voltage is 2 MV and the maximal current is over 600 kA. The problems occurring during experiments are summarized and analyzed, and corresponding improvement measures are proposed.
-
Key words:
- laser trigger /
- gas switch /
- delay /
- jitter /
- self-breakdown
-
